Factory customized FOTON AUMAN 8*4 LHD 40CBM 270hp Euro 3 hydraulic discharging poultry animal feed transported truck
Factory customized FOTON AUMAN 8*4 LHD 40CBM 270hp diesel hydraulic system discharging poultry animal feed transported truck for sale, HOT SALE! FOTON 20tons farm-oriented and livestock bulk feed delivery truck
Foton Auman 8*4 feed transportation truck is with the volume of 40 cubic meters with 4 compartments for 4 different feed pellets. The bulk feed pellet truck adopts three phrase 380volts electronic auger for discharging, and the discharging speed up to 1cbm/min or o.6tons/min. And the discharging height of Foton Auman 8*4 feed delivery truck is about 8.5m, fully meeting the filling requirements of feed storage van for breeding bases.
The bulk feed tank volume is 40bm(can be loaded 20n feeds according to the density of the bulk feeds), adopting hydraulic auger type to feeds. Discharging is by hydraulic system driven the screw mechanism with high speed, continuous working, highly improving the working productiveness. .
The feed tank is usually with 4 compartments, loading and discharging with four different kinds feeds. Simple unit structures. electric cabinet unity is at the rear part of the tank. Easy and flexible to operate and maintenance.
If you're interested in our bulk feed truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat: +86 13329899995.
Website: www.trucksinchina.com
More pictures of FOTON AUMAN 8*4 LHD 20tons hydraulic discharging feed transported truck manufactured by Chengli Special Automobile Co., Ltd. as below.
FOTON AUMAN 8*4 LHD 40m3 animal feed transported vehicle for sale
HOT SALE! high quality and competitive price FOTON AUMAN 20tons hydraulic discharging poultyr feed truck for sale
More pictures of FOTON AUMAN 8*4 LHD 270hp Euro 3 hydraulic discharging feed transported truck as below
| Main technical parameters | ||
| Product name | FOTON AUMAN 8*4 LHD hydraulic feed truck | |
| Overall dimension(L*W*H) (mm) | 11950×2500×3600 | |
| Volume | 40m3 | |
| Curb mass(Kg) | 11805 | |
| Max speed | 80km/h | |
| Transmission | Fastgear 9 speed transmission | |
| Tyre nos. | 12+1*11.00-20 18PR | |
| Driver cab | FOTON AUAMN luxurious driver cab with air conditioner | |
| Engine model |
SC9DK270Q3B1
|
|
| Engine emission standard | Euro 3 | |
| Engine power | 199KW/270hp diesel engine | |
| Engine displacement(ml) | 8820ml | |
| Feed tank | ||
| Volume | 40cubic meters | |
| Discharging way | Hydraulic system discharging | |
| Compartments | 4 compartments with 4 different kinds feed | |
| Average discharging speed(kg/min) | 500-600 kg/min or 1m3/min | |
| Full discharging time (minutes) | About 35 minutes | |
| Rotation angle of auger when discharging | ±180 degree | |
| max elevation angle of auger when discharging | 70 degree | |
| Discharging rotation degree | Unilateral 180 degree | |
| Delivery distance | Horizontal max range(m) | 6.5 |
| Vertical max range(m) | 8.3-8.5m | |
| Residual rate | No more than 0.10 | |
