Factory sale competitive price CLW brand 20MT surface propane gas storage tank, new best selling 40m3 bulk lpg tank
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of lpg gas pressure vessels in China. With many years’ development, Chengli Special Automobile Co., Ltd. could manufacture and sell surface lpg gas storage tank, underground lpg gas storage tank, lpg gas trailer, lpg gas truck, skid lpg gas refilling plant, etc. More information, please feel free to contact with Ms. Anita. Last year, Our CLW brand lpg gas pressure vessels have passed US ASME standard. Our CLW brand lpg gas pressure vessels have been exported to so many countries all over the world. More information, please feel free to contact with Ms. Anita.
Technical Advantages of LPG gas tank manufactured by Chengli Special Automobile Co., Ltd. as below
a.) Fixed-point procurement of raw material manufacturer
b.) Strictly inspection for incoming material
c.) Vigorous production process
d.) Nondestructive examination / 100% X-ray testing
e.) Water pressure and air tightness testing
f.) Excellent safety device, long service time
Tank shaped use the advanced welding technology, end socket arc butt welding, and the once-forming of composite steel-plastic technology. Equipped with active and passive safety devices to meet an emergency and can load and unload the material in long distance and completely close condition. Be applied to transport varied oil, fuel and chemical material, such as natural gas, liquefied petroleum gas, liquefied ammonia, carbon bisulfide, epoxy ethane,gas, butane, dimethylmethane, propylene, etc. Cross section of tank could be oval, round and round-square. heat insulation and heating device is optional.
| Item | Unit | Main parameters |
| Product name | LPG gas storage tank(40,000L) | |
| Product model | CLG2300-40 | |
| Loading medium | LPG gas (propane) | |
| Overall dimension(L*W*H) | mm | 10,040*2,324*2,914 |
| Tank dimension(inner diameter*thickness*length) | mm | DN2300*14*10,040 |
| Tank volume | m3 | 40 |
| Tank thickness | mm | 14 |
| End heads thickness | mm | 12 |
| Curb mass | kg | 8,300 |
| Real loading capacity | Kg | 15,960 |
| Designed pressure | Mpa | 1.77 |
| Working pressure | Mpa | ≤1.6 |
| Working temperature | ℃ | ≤50 |
| Hydraulic test pressure | Mpa | 2.22 |
| Air tight test pressure | Mpa | 1.77 |
| Tank and main Material pressure components | Q345R,16Mnlll | |
| Standard |
<<GB150steel pressure vessel>>,<<Supervision Regulation on Safety Technology for Pressure Vessel>>
|
|
| Chosen accessories |
Safety valve, magic level gauge, pressure gauge, temperature gauge, cut-off valve, etc.
|
|
