best price 20MT new electronic discharging bulk feed tank container semitrailer, road transported bulk feed tank
best price 20MT electronic system discharging bulk feed tank container semitrailer, road transported bulk feed tank for sale
Chengli Special Automobile Co., Ltd. is the leading manufacturer of bulk feed delivery truck, animal feed tanker truck in China since 2004s. With many years’ development, the animal feed tanker trucks manufactured by Chengli Special Automobile Co., Ltd. are with simple structure, reliable performance, large delivery amount, easy operation, etc. suitable for feed transporting of different sizes farms.
Bulk feed tank delivery truck manufactured by our company is a kind of special transportation vehicle refitted on the second type chassis or the cargo trucks clients offered, then choosing the high quality and high strength carbon steel, welded the tank; equipped with electronic auger discharging system. Bulk feed tank is made up of chassis, loading feed pellet tank, discharging auger system and electro hydraulic operation system, etc.
Bulk feed delivery truck is main used for delivering, loading and discharging of feed pellets of different feed factories, large-type poultry farms, and also for transporting some non-corrosive feed pellets, such as pellets from pharmaceutical factory and turnover of grain depots, etc. the feed trucks manufactured by Chengli Special Automobile Co., Ltd. can transporting various feed pellet with the different compartments, the dream transporting vehicles for poultry farms and feed factories.
If you're interest in our bulk feed tank container, please kindly send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
Main technical parameters of 20MT-23MT electronic discharging bulk feed tank semitrailer manufactured by Chengli Special Automobile Co., Ltd. as below.
| Main technical parameters | |
| Product name | bulk feed trailer(40m3-45m3) |
| Overall dimension(L*W*H) | 11500*2500*3990 |
| Total mass(kgs) | 38100 |
| Wheelbase(mm) | 7590+1310+1310 |
| Approach/departure angle | -/14 |
| Front/rear Suspension (mm) | -/2290 |
| Front/rear tread(mm) | -/1840;1840;1840 |
| Leaf spring | -/8/8/8,-/10/10/10 |
| Axle load(kgs) | -/23100(triple axles) |
| Axle nos. | 3 |
| Axles brand | 3*13tons FUWA axles |
| Outriggers | 28tons outriggers |
| Tires specification | 11.00-20*12+1 |
| Tractor pin | 50# |
| Toolbox | One set |
| Spare tire supports | 2 |
| Volume | 40m3/45m3 |
| Loading capacity | According to the proportion( feed proportion is from 0.4tons/m3 to 0.55tons/m3) |
| Feed tank material | High quality carbon steel |
| Compartment | 4 separate compartments for 4 different kinds feed |
| Discharging speed | 500-600 kg/min or 1m3/min |
| Discharging way | Electronic system discharging |
| Generator unit | Install one set of diesel generator unit to generate electricity |
| Vertical feeding height | 8.5m |
| Horizontal distance | 6.8m |
| Surplus ratio | ﹤0.1 |
Triple axles 40-45cbm bulk feed tank semitrailer, adopts 3 sets of FUWA 13ton bridges, 11.00-20 tyre, 28ton outriggers, 90# /50# traction pin, etc.
The bulk feed tank volume of 40-45cbm, with the loading capacity of about 20tons, adopts high quality 5mm carbon steel, transferring feeds by electronic auger, working with putting on 380volts electronic power. The electronic motor drives the Mechanical auger screw type to discharge with high discharging speed of 0.55ton/min. The Barrel type auger at the tank top is driven by the hydraulic motor, and the electronic bottom control lifting up and down, rotation left and right, with the horizon range of 7.2m and vertical range of 8.2m. So little Residual rate, less than 0.1. And the feed pellet semitrailer can be continuous working, highly improving the working productiveness.
There are 5 compartments of the feed trailer, 5 separate compartments with 5 different kinds of feeds. Every unit is with simple structure, easy and flexible operation, easy to maintenance, etc.
more pictures of CLW brand bulk feed tank container semitrailer as below
HOT SALE! bulk feed tank container semitrailer
high quality and competitive price CLW Brand 20MT bulk feed tank semitrailer for sale
More information, please feel free to contact with Ms. Anita.
Whatsapp/Wechat/Mob.: +86 13329899995
SKype: truck0011
QQ: 504873236
