HOT SALE! Customized CLW 10tons skid lpg gas station with 2 lpg gas dispensers, skid lpg gas tanker with lpg dispensers
HOT SALE! Customized CLW Brand 10tons skid lpg gas refilling station with double lpg gas dispensers, skid lpg gas tanker with double lpg gas dispensers for gas cylinders for sale
Nowadays, more and more clients choose to purchase mobile skid lpg gas plant for their lpg gas plant business. We Chengli Special Automobile Co., Ltd. can customize skid lpg gas plant with digital scales for filling domestic gas cylinders or automatic lpg gas dispenser for automobiles or gas cylinders. The lpg gas dispensing machine is with single filling gun or double filling guns for filling single gas cylinders or double gas cylinders at one time.
CLW brand skid lpg gas refilling station with double lpg gas dispensers( double filling nozzles to fill double gas cylinders at one time) is finished. This unit of skid lpg gas bottling plant is customzied for client from Africa, one simple complete lpg gas refilling station which is very suitbale for small lpg gas plant.
The specification of customized 12m3 skid lpg gas refilling station with lpg gas dispenser manufactured by Chengli Special Automobile Co., Ltd. as below.
| Item | Model | Unit | No. | Remark |
| Lpg gas storage tank | 20,000Liters | Piece | 1 | Standard skid with low frame base (designed into load one 40’HQ container) |
| Hydrocarbon pump | YQB15-5 | Piece | 1 | Driving belt with cover,pump base |
| Explosion-proof three-phase asynchronous motor | 5.5KW | Piece | 1 | |
| Concentration alarm | - | Piece | 1 | |
| Lpg gas dispenser(with double filling nozzles) | China made | Piece | 1 | |
| Explosion-proof control box | - | Piece | 1 | |
| Floating ball level meter | UQZ-6 | Piece | 1 | |
| Temperature gauge | M33*1.5 1.5 grade 0～4mpa | Piece | 2 | |
| Safety valve | DN80 | Piece | 1 | |
| Globe valve | DN80 | Piece | 1 | |
| Safety backflow valve | AH42F-25 DN25 | Piece | 1 | |
| Y-Strainer | GL41H-25 DN50 | Piece | 2 | |
| Globe valve | J41W-40 DN50 | Piece | 5 | |
| Ball valve/check | Q41F-40 DN50 | Piece | 5 | |
| Discharging pipe | L=4m DN50 | Piece | 2 | |
| check valve | M42N-25 DN50 | Piece | 1 | |
| Sprinkling | Piece | 1 | Galvanized tube | |
| Needle valve | DN6 | Piece | 3 | |
| Ball valve | DN15 | Piece | 1 | |
| damper tube | - | Piece | 1 |
