factory direct sale Bigger 6.8m length 40000 baby ducks transported truck for sale, good quality live poultry vehicle
The baby chick trucks manufactured by Chengli Special Automobile Co., Ltd. adopts high quality Fiberglass Reinforced Plastic (FRP) for exterior and interior layer, and the middle insulation layer with 80mm PU foam sheets.
And we can customized the day old chick trucks, installed with cooling system, heating system, Ventilation system, windows and fans, etc. More information, please feel free to contact with Ms. Anita.
Truck for transported day old chick is a kind of special insulation van truck for transporting day old chickens and eggs, etc. It is suitable for large chick farms, etc.
High-Tech Day Old Chicken Truck transporting
1)Day old chicken truck adopt with whole skeleton of the “sandwich” plate bonding process,
2)Inner and outer plate use glass fiber reinforced plastic (GFRP) and steel; so have thermal insulation ;
3)Intermediate insulation materials used 7cm thick imported polyurethane;
4)Surroundings use aluminum edge;
5)Bottom plate use steel and wood to fix the body, good insulation and nice overall intensity. so the frame have firm and better load bearing.
6) The bottom plate use optional ventilation slots to facilitate air-conditioned flow of the entire cargo, and maintain the balance of the temperature.
If you're interested in our day old chicks transported vehicle, please kindly send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995. Website: www.trucksinchina.com
More pictures of CLW brand day old chicks transported vehicle manufactured by Chengli Special Automobile Co., Ltd. as below.
High quality and best price dongfeng baby live poultry transported truck for sale
HOT SALE! Dongfeng D9 180hp diesel 6.8m length day old chicks transported vehicle for sale
The specification of CLW brand day old chicks transported van car as below.
| Product name | Dongfeng D9 4*2 LHD day old chick transported truck | ||
| Overall dimension(L*W*H)(mm) | 9080×2500×3850 | Chick van box dimension(L*W*H)mm | 6800*2340*2470 (mm). |
| Drive type | 4*2 LHD | Total mass | 16000 |
| Gearbox | Fastgear 8 speed transmission, manual | Tyre specification | 9.00R20 rail tyres *6+1 |
| Power steering | Yes | Exhaust braking | Yes |
| Air cut braking | Yes | Driver cab | Dongfeng D9 one row and a half driver cab |
| Engine | ISB180 50 | Emission standard | Euro Ⅴ |
| Rater power | 132KW/180hp | Displacement (ml) | 5990 |
Main technical parameters of day old chick van body
| Performance and consumption | |||
| Heating system | Watering system | Without, client choose to install | |
| Cooling system | One refrigerated reefer | China made high quality vehicle-powered refrigerated reefer( the lowest temperature inside the cold room box up to -10℃, adjusted at the driver cab) | |
| Ventilation system | Air duct installed on the floor for air flow | three line as the pictures show | |
| Cold air ducts on the two sides of the van body | three cold air ducts for the refrigerated reefer | ||
| Blind windows | 5 sets of blind windows for the left and right van sides (as the pictures show); one bigger water-proof blind window at the front van plate. Blind Windows: 5*2+1=11 |
||
| electronic ventilator fans | 1, 4 sets of electronic ventilator fans with sliding doors for the rear plate door; 4 sets of electronic ventilator fans for the van top Electronic fans: 4+4=8 |
||
| Sky-window | Top mounted sky windows*2 Sky-windows: 2*1=2 | ||
| Sliding window | One sliding window at the front van plate(as the picture show) | ||
| Dimension | |||
| Chick van box body | Length | 6800mm | |
| Width | 2340mm | ||
| Height | 2470mm | ||
| Refrigerated van box | Exterior and interior with FRP( fiber reinforced plastic), and the middle with 80mm PU slices; Aluminum-patterned baseplate; |
||
