main technical parameters of dongfeng DLK mobile LED advertising truck manufactured by Chengli Special Automobile Co., Ltd. as below.
2. Engine: Euro 3 emission standard diesel engine 120hp
3. Led box body: 3 sides P5 led screens, led screen size: left and right 4800*2080mm, rear 1600*1600mm
4. With OUMA 25KW silent diesel generator, industrial computer with control system, 4 waterproof speakers, 1 amplifier, 1 console.
5. Optional: 1 side led screen, 2 sides led screen, lifting system for led screen, mobile stage, 4 hydraulic legs, etc.
| Classification | Item | Unit | Parameter |
| Vehicle | Vehicle model | Dongfeng DLK led advertising truck | |
| Manufacturer | Cheng Li Special Automobile Co.,Ltd | ||
| Overall dimensions | mm | 7290×2330×3350 | |
| Curb weight | kg | 7205 | |
| Traction system | 4×2 | ||
| Max speed | km/h | 90 | |
| Chassis | Chassis model | EQ1090T9ADJ3AC | |
| Manufacturer | DongFeng Automobile Co., Ltd | ||
| Number of axles | 2 | ||
| Wheel base | mm | 3800 | |
| Tire specification | 7.50R16 | ||
| Number of tires | 6+1 spare | ||
| F/R track base | mm | 1770/1586 | |
| Engine | Engine model | YC4FA120-33 | |
| Manufacturer | GuangXi YuChai Machinery Co., Ltd | ||
| Fuel type | Diesel | ||
| Power | kw | 88 | |
| Engine horse power | hp | 120 | |
| Displacement | ml | 4260 | |
| emission standard | Euro 3 | ||
| Driver’s cab | Brand | DongFeng | |
| Model | Flat head, single row | ||
| Allowable seats | 2 | ||
| Steering | Left hand drive | ||
| Transmission | 5-speed with over drive | ||
| Operation control system | Electrically hydraulic control | ||
| Air-conditioning | Optional | ||
| Standard equipment |
1> 3 sides (left, right and rear) P5 waterproof full color led screen; 2> Both sides hydraulic lifting system for screens; 3> With 4 hydraulic legs and left side 14.5 m2 mobile hydraulic stage; 4> With GREE 1.5P air conditioner in the van; 5> 5cm composite steel box, aluminum alloy pattern plate floor; 6> Inside and outside the electric distribution box; 7> Loop ventilation cooling system; 8> Ouma silent diesel generator; 9> One industrial computer with control system, 4 waterproof speakers, 1 amplifier, 1 console; 10> Video processor for 3 sides screens. |
||
| Color &Painting | White | ||
| FOB Shanghai | USD | ||
