2021sbest price dongfeng D9 190hp 10tons dump truck for transported stone, coal, sand soil for sale, tipper vehicle
HOT SALE!Dongfeng D9 dump tipper truck for sale
Dump truck is also called tipper, dump tipping vehicle, sand and stone transporting vehicle, etc. Dump truck is mainly used for transporting loose material (such as sand, gravel, or dirt) for construction. A typical dump truck is equipped with an open-box bed, which is hinged at the rear and equipped with hydraulic pistons to lift the front, allowing the material in the bed to be deposited dumped on the ground behind the truck at the site of delivery.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of dump truck in China since 2004s. And we can offer dongfeng dump truck, HOWO dump truck, ISUZU tipper truck, FAW dump tipper, North Benz dump truck, tipper trailer, etc. 4*2 dump truck, 4*4 dump truck, 6*4 tipper truck, 8*4 dump truck, etc. More information, please feel free to contact with Ms. Anita Deng.
If you're interested in our dump truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Dongfeng D9 new face dump truck adopts new face dongfeng D9 one row and a half driver cab, 394500mm wheelbase, 5ton front axle/10tons rear axle, fastgear 8 speed gearbox. 10.00R20 rail tires * 6+1, 250mm double layers boom, etc.
The overall dimension of dongfeng D dump truck is 7850×2500,2550×2850,3100,3360 (mm), and the dump box body dimension(L*W*H) is 5400×2300×600/800(mm).
More pictures of dongfeng D9 5.4m length dump tipper truck manufactured by Chengli Special Automobile Co., Ltd. as below.
Main technical parameters of dongfeng D9 10tons dump tipper truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Items | Descriptions | Specifications and Types |
| General | Truck Name | Dongfeng D9 190hp diesel dump tipper truck for sale |
| Drive Type | 4*2, LHD | |
| Loading capacity | About 10tons | |
| Gross Vehicle Weight(kg) | 18000kgs | |
| Curb Weight (kg) | 7000kgs | |
| Rated weight(kgs) | 10000kgs | |
| Overall Dimensions L*W*H(mm) | 7850×2500,2550×2850,3100,3360 | |
| Engine | Engine Model | B190 33 |
| Fuel Type | Diesel | |
| Power | 140kw/190HP | |
| Emission Standard | Euro Ⅲ | |
| Displacement(ml) | 5900 | |
| Engine Type | 6 cylinders in line,water cooling, turbocharged diesel engine,inter-cooling, electric control | |
| Chassis | ChassisBrand | Dongfeng |
| Front/Rear Axle Load(KG) | 6500/11500 | |
| Tire No. | 6 | |
| Tire Specification | 10.00R20 | |
| Wheelbase (mm) | 4500 | |
| Axle No. | 2 | |
| Gear Box | Fastgear 8 speed gearbox | |
| Front/rear suspension(mm) | 1260/2090 | |
| Front/rear tread(mm) | 1933/1865 | |
| Leaf Spring No. | 8/- | |
| Driver cab | Dongfeng D9 one row and a half driver cab | |
| Tipping system | Box inner dimension(mm) | 5400×2300×600/800 |
| Box material | Carbon steel,side 3mm,bottom 4mm | |
| Hydraulic cylinder no.(set) | 2 | |
| Hydraulic cylinder position | At the center of the truck bottom | |
| Discharge type | Rear tipping |
