Customized SHANGQI Datong V90 diesel engine Refrigerated minivan for sale, New cold van truck for transported vaccines
Customized SHANGQI Datong V90 diesel engine Refrigerated minivan for sale, New cold van truck for transported vaccines and pharmaceutical products for sale,
CLW brand refrigerated truck adopts Exterior and interior with FRP(Fiber Reinforced Plastic), and the middle with PU slices with vacuum negative pressure one-formed casting as the insulation layer, approved the related Ministry of Health of food grade requirements, etc. just like sandwich structure. Baseboard adopts anti-skipping diamond board, which assuring the insulation ability and the compact resistance of the baseboard. double rear door opened. Choose high quality China made self-powered frozen refrigerating reefer of the model of T-800M, the lowest temperature is up to -18℃. And the reefer can be adjusted at the driver cab.
The cold room van body is install stainless steel material pharmaceutical products ventilation slots and temperature and humidity recorder with printing function and GPS (Global Positioning System).
Chengli Special Automobile Co., Ltd manufactures refrigerator trucks since 2004s in China. With so many years’ experience in manufacturing, we Chengli Special Automobile Co. Ltd could manufacture and sell vaccine delivery vehicle, meat hook refrigerated truck, fruit and vegetables refrigerated truck, milk food transport refrigerator truck, insulation van truck, van refrigerated truck, freezer minibus, small refrigerated truck, medium freezer van truck, big refrigerated truck, refrigerator semi-trailer, freezer refrigerated vehicles, dongfeng brand cold room truck, ISUZU brand refrigerated truck, FAW refrigerated truck, FOTON refrigerated truck, Chang’an freezer van truck, Yuejin refrigerated truck, JMC refrigerated truck, CMAC refrigerator truck, Aoling refrigerated truck, the smallest refrigerated truck, etc. More information, please feel free to contact with Ms. Anita.
If you're interested in our refrigerated truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
Shangqi DATONG V90 diesel engine refrigerated truck for sale,
Truck model: SH5043XXYH7DB-S
wheelbase: 3760mm
overall dimension (L*W*H): 5940×2110×2745mm (mm)
refrigerated van box dimension(L*W*H): 2960×1620×1580mm(mm)
Engine model: SC20M150Q6 150hp diesel engine
gearbox: 6 speed gearbox
curb mass: 3200KG
Tire specification: 195/75R16LT *6
More pictures of SHANGQI Datong V90 diesel refrigerated minivan manufactured by Chengli Special Automobile Co., Ltd. as below.
Main technical parameters of shangqi datong V90 diesel refrigerated minivan as below.
| Items | Descriptions | Specifications and Types |
| General | Truck Name | Shangqi datong V90 diesel mini refrigerator truck for sale |
| Drive Type | 4*2 LHD | |
| Fact Loading Weight(kg) | 1tons-1.5tons | |
| Total mass(kgs) | 4495kgs | |
| Curb Weight (kg) | 3200(Kg) | |
| Overall Dimensions (mm) | 5940×2110×2745 (mm) | |
| Engine | Engine Model | SC20M150Q6 |
| Engine Brand | SHANGHAI DIESEL ENGINE | |
| Fuel Type | DIESEL | |
| Power | 150hp | |
| Emission Standard | Euro Ⅵ | |
| Chassis | Chassis model | SH5043XXYH7DB-S |
| Chassis Brand | SHANGQI DATONG | |
| Tire Specification | 195/75R16LT *6 | |
| Wheelbase (mm) | 2850mm | |
| Axle No. | 2 | |
| Steering Wheel | Left hand drive | |
| Gear Box | 6 speed forward with 1 reverse, manual | |
| Air-conditioner | No | |
| Cold Room | Box inner dimension(mm) | 2960×1620×1580 |
| Box Side | Exterior and interior with FRP(Fiber Reinforced Plastic), and the middle with 80mm PU slices with vacuum negative pressure one-formed casting as the insulation layer, approved the related Ministry of Health of food grade requirements, etc. just like sandwich structure. | |
| Box Floor | Baseboard adopts aluminum alloy anti-skipping diamond board, which assuring the insulation ability and the compact resistance of the baseboard. | |
| Doors |
Frame of standard rear double doors adopts the stainless steel structure frame with light mass and perfect corrosive resistance, etc. The door edgings frames are sealed with the imported high quality epdm rubber, making sure the van insulation stability. Aluminum alloy Door edgings, Stainless steel material Door locks and accessories |
|
| Refrigerator Unit | Refrigeration unit | Choose high quality China-made vehicle-powered refrigerated unit, the temperature can be adjusted at 15 degree below zero to zero degree. And the cooling unit can be adjusted at the driver cab. |
| Refrigerated temperature | -15° to 0° |
