SHACMAN brand 8*4 F3000 LHD 40tons dump tipper truck for ore/gravel/coal transportation, heavy duty dump tipper for sale
HOT SALE! SHACMAN brand 8*4 F3000 LHD 40tons dump tipper truck for ore/gravel/coal transportation, heavy duty dump tipper for sale
HOT SALE! SHACMAN brand 8*4 LHD F3000 dump tipper truck, adopts Shacman strengthen F3000 luxurious driver cab with air conditioner, 1800+3975+1400mm wheelbase, WP12.400E201 400hp diesel Euro 2 engine, 10JSD180+QH50 10 speed gearbox+PTO, MAN 9.5T front axle/16T MAN dual grade rear axles, 400Liters aluminum alloy oil tanker, 12.00R20 rail tires, etc.
And the overall dimension (L*W*H) of SHACMAN brand F3000 dump tipper truck is 10730×2490×3450 (mm); while the dump tipper box dimension(L*W*H) is 7800×2300×1500(mm). The loading capacity of SHACMAN brand 8*4 LHD diesel dump tipper truck is 40tons-50tons.
If you're interested in our dump tipper truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of SHACMAN brand diesel dump tipper truck manufactured by Chengli Special Automobile Co., Ltd. as below.
HOT SALE! SHACMAN Brand dump tipper truck for sale
High quality and best price SHACMAN dump tipper truck for ore/gravel/coal transportation
Factory sale SHACMAN brand 400hp diesel dump tipper truck for sale
Main technical parameters of SHACMAN brand diesel dump truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Items | Descriptions | Specifications and Types |
| General | Truck Name | SHACMAN 6*4 LHD dump truck for sale |
| Drive Type | 6*4, LHD | |
| Loading capacity | -25,000KGS | |
| Gross Vehicle Weight(kg) | 25000(Kg) | |
| Rated weight(kgs) | 12670(Kg) | |
| CurbWeight (kg) | 12200(Kg) | |
| Overall Dimensions L*W*H(mm) | 10730×2490×3450 (mm) | |
| Dump tipper box dimension(L*W*H) | 7800×2300×1500(mm) | |
| Engine | Engine Model | WP12.400E201 |
| Fuel Type | Diesel | |
| Power | 294KW/400HP | |
| Emission Standard | Euro II | |
| Displacement(ml) | 9726 | |
| Chassis | Chassis Brand | SHACMAN |
| Drive type | 8*4 LHD | |
| Front/Rear Axle Load(KG) | 6480/6480/17700 | |
| Tire No. | 12 | |
| Tire Specification | 12.00R20 rail tires | |
| Wheelbase (mm) | 1800+3975+1400mm | |
| Axle No. loading capacity | MAN 9.5T front axle/16T MAN Bipolar axles | |
| Gear Box | 10JSD180+QH50 gearbox gearbox, manual | |
| Brake | Air brake | |
| Air Conditional | Yes, original air conditioner, | |
| Front/rear suspension(mm) | 1525/2055(mm) | |
| Leaf Spring No. | 13/13/12 | |
| Driver cab | F3000 Standard roof cabin with A/C | |
| Tipping system | Box inner dimension(mm) | 5600/5800x2300x1500 (mm) |
| Box material | Q345 Carbon steel,side 6mm,bottom 8mm | |
| Dump box body shape | Rectangular box shape | |
| Hydraulic cylinder no.(set) | Single one | |
| Hydraulic cylinder position | Front installed hydraulic cylinder #180 | |
| Discharge type | Rear tipping | |
| Remark | Clients choose to install top mounted hydraulic environmental protection cover. | |
