Customized ISUZU LHD diesel Euro 5 Mobile LED truck with 3 sides P5 LED screen for sale,LED screen vehicle supplier
Customized ISUZU brand 98hp diesel Euro 5 Mobile LED truck with 3 sides P5 LED screen for Cameroon, HOT SALE! LED screen vehicle supplier in China
The mobile led display truck is also called advertising box truck, advertising van, truck mobile advertising led display, mobile led truck, etc.The mobile led screen truck consist of chassis, led screen, light box, generator, PC controller, loudspeaker, etc. It mainly used to display the advertising across the city for supermarket, government, large company, etc.
As a professional and leading china led truck manufacturer in China, the clw brand led truck for sale have more advantages than others:
1. P6,P5 and P4 full color led screen for optional, meet all customer's requirement.
2. Side screen can be lifted 1.5m for stage performance,good visual effect
3. Double color scrolling marquee on the rear door.
4.Equipped with high quality play devices. perfect listening effect.
5.Super-silent generator, save electricity, environmental protection
6.Luxury wood floor with plastic flooring.
If you're interested in our mobile LED advertising truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
More pictures of ISUZU 4*2 LHD mobile LED advertising truck manufactured by Chengli Special Automobile Co., Ltd. is as below.
HOT SALE! ISUZU brand 4*2 diesel mobile LED advertising truck
main technical parameters of ISUZU brand 4*2 LHD P5 mobile LED advertising truck as below.
| ISUZU 4*2 LHD mobile LED vehicle for sale(with three sides P5 LED screen) main parameters | |||
| Product name | New ISUZU brand 4*2 LHD mobile LED screen truck with three sides P5 LED screens for sale | ||
| Overall dimension(L*W*H) | 5995×2040×2990(mm) | Truck chassis model | QL1040A6HAY |
| Total mass(kgs) | 4495kgs | curb mass(kgs) | 4365kg |
| Axle nos. | 2 | Wheelbase(mm) | 3360mm |
| Front/rear suspension(mm) | 1015/1620 | Front/rear tread(mm) | 1377/1425 |
| Rated person | 2 (driver included) | Tyre specification | 7.00R16 rail tires*6 |
| Max speed(km/h) | 98 | Approach/departure angle | 24/12(°) |
| Axle load(kgs) | 1865/2690 | Steel spring | 3/3+2 |
| Gearbox | ISUZU MSB 5 speed gearbox, manual | Power steering | Yes |
| brake | Oil cut brake with vacuum booster | Driver cab | ISUZU 100P single row luxurious driver cab with original air conditioner and engine brake |
| Engine model |
4KH1CN5LS
|
Emission standard | Euro Ⅴ |
| Displacement(ml) | 2999ml | Rated power | 72KW/98hp |
| Fuel type | Diesel | ||
| Truck mounted LED screen | |||
|
1
|
two sides of the driver cab are with high quality HD waterproof and shake-proof full color outdoor P5 LED screens ( One side P5 screen area: 3840*1760=6.75㎡) | ||
| 2 | The rear back face is also with single color word LED screen(rear door single color word LED screen area: 1280*1440=1.84㎡) | ||
| 3 | One side(left or right side) P5 LED screen can be hydraulic sliding up-down(1.5m); 10㎡ platform stage with double outriggers. | ||
| 4 | Truck mounted silence diesel generator adopts high quality OUMA 15KW diesel generator unit. | ||
| 5 |
1* high quality industrial computer, 1* amplifier 4 *waterproof Audios mains electricity interface, 30m power line 2*top-mounted sky-windows Top roof with high quality glass fiber-reinforced plastics( FRP), aluminum checkered plate floor |
||
|
Remark: the computer is with English words, English operation system and Software playback system HS code: 8705909990 |
|||
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of Outdoor mobile LED advertising display truck, LED truck, digital advertising truck, LED screen truck, outdoor full color LED advertising truck, LED box truck, etc. With many years' experience in supplying, Chengli Special Automobile Co., Ltd. could design and produce ISUZU led truck, Dongfeng Outdoor mobile LED advertising display truck, forland digital advertising truck, Karry billboard advertising LED display truck, Chang'an LED display truck, JAC mobile advertising truck, HOWO scrolling advertising truck, trailer-type mobile outdoor LED truck, etc. More information, please feel free to contact with Ms. Anita Deng.
