HOT SALE! YUEJIN brand 4*2 LHD gasoline Euro 6 engine P5 mobile LED advertising truck, LED screen vehicle for sale
HOT SALE! YUEJIN brand 4*2 LHD gasoline Euro 6 engine P5 mobile LED advertising truck, LED screen vehicle for sale
The mobile led display truck is also called advertising box truck, advertising van, truck mobile advertising led display, mobile led truck, etc.The mobile led screen truck consist of chassis, led screen, light box, generator, PC controller, loudspeaker, etc. It mainly used to display the advertising across the city for supermarket, government, large company, etc.
1. Mobile LED advertising trucks is also named as mobile LED screen trucks, LED advertising vehicles, LED billboard truck, mobile truck LED display. etc.
2. Widely used for outdoor commercial advertising, stage rental, traffic advertising, mobile truck advertising, sports stadium advertising, live shows, etc.
3. One side waterproof P4/P5/P6 full color led screen. The other side advertising light box with subtitle. The rear side monochrome screen to display text.
4. Optional1-side, 2-sides or 3 sides full-color led screens. Brightness can be adjusted automatically according to different surroundings.
If you're interested in our mobile LED advertising truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
Today, we will introduce BEST SELLER-YUEJIN 4*2 LHD gasoline engine P5 mobile LED advertising truck for sale is as below.
More pictures of YUEJIN 4*2 LHD gasoline engine P5 mobile LED advertising truck as below.
main technical parameters of YUEJIN brand 4*2 LHD gasoline mobile LED advertising truck is as below.
| YUEJIN 4*2 LHD mobile LED vehicle for sale(double sides P5 LED screen) main parameters | |||
| Product name | New YUEJIN 4*2 LHD mobile LED screen truck with two sides P5 LED screens for sale (gasoline engine) | ||
| Overall dimension(L*W*H) | 5180×1760×2820 (mm) | Truck chassis model | SH1033 |
| Total mass(kgs) | 2930kgs | curb mass(kgs) | 2800kg |
| Axle nos. | 2 | Wheelbase(mm) | 2650mm |
| Front/rear suspension(mm) | 1090/1440 | Front/rear tread(mm) | 1316/1223 |
| Rated person | 2 (driver included) | Tyre specification | 175R14LT 8PR *6 |
| Max speed(km/h) | 100 | Approach/departure angle | 18/11(°) |
| Axle load(kgs) | 1170/1760 | Steel spring | 3/4+5 |
| Gearbox | 5 speed gearbox, manual | Power steering | Yes |
| ABS | YES | Driver cab | YUEJIN xiaofuxing S70 single row driver cab |
| Engine model | LJ4A15Q6 | Emission standard | Euro Ⅵ |
| Displacement(ml) | 1499ml | Rated power | 83KW/114hp |
| Fuel type | Gasoline | ||
| Truck mounted LED screen | |||
|
1
|
two sides of the driver cab are with high quality HD waterproof and shake-proof full color outdoor P5 LED screens ( One side P5 screen area: 2560*1440mm=3.69㎡) | ||
| 2 | The rear back face is also with single color word LED screen(rear door single color word LED screen area: 960*1280=1.23㎡) | ||
| 3 | One side(left or right side) P5 LED screen can be hydraulic sliding up-down(1.2m); 4㎡ platform stage with double outriggers. | ||
| 4 | Truck mounted silence diesel generator adopts high quality YIHU 15KW gasoline generator unit. | ||
| 5 |
1* high quality industrial computer, 1* amplifier 4 *waterproof Audios mains electricity interface, 20m power line 2*top-mounted sky-windows Top roof with high quality glass fiber-reinforced plastics( FRP), aluminum checkered plate floor |
||
| RRMARK |
1, the production time is about 15days. 2, the price is valid for one month. 3, Payment Term: T/T 50% as deposit, then the balance (50%) will be T/T before shipping. |
||
The main technical parameters of FOTON xiangling V1 truck head as below
Truck model: CLW5030XXCSH6
Overall dimension (L*W*H): 5180*1760*2820mm
YUEJIN S70 mobile LED advertising truck, 2650mm wheelbase, LJ4A15Q6 112hp gasoline Euro Ⅵ engine, 185R15LT 8PR tires*4, 5 speed manual gearbox, power steering and ABS, etc.
The upper part of the YUEJIN 4*2 LHD p5 Mobile LED advertising truck with P4/P5/P6 LED screen as below.
1, LED screen
driver cab side: outdoor colorful LED screen, p6/p5 /p4 is selective
P6 colorful LED screen: 2304*1536mm
P5 Colorful LED screen: 2560*1440mm
P4 color LED screen: 2560*1440mm
front lintel singe red word screen(P10) dimension(L*W):960*320mm
Rear door single red word screen(P10) dimension(L*W): 960*1280mm
2, Roller advertising light box:
front passenger seat side: glass Roller advertising light box with Play 3-5 sets of advertisings in loop(if choose double sides LED screens, then without Roller advertising light box).
3, Power supply system
Gasoline generator unit* 1 set, YIHU brand
Type: Air cooling, electric start, manual start
Power: 6.5kw(for single side LED screen);
8kw(for double sides LED screens)
Internal and external power switching device, 220V mains interface
4, Operation system
Computer: industrial computer*1 set, AOC monitor.
Control software: Yangbang or Colorlight.
Amplifier: Yvette broadcast-grade amplifier, power: 200W.
Waterproof sound column: 2 pieces, power: 30W.
5, 【ventilation system】
One top ventilation skylight, front louver ventilation design,
The generator base is equipped with a high-power exhaust fan.
6, [Car body craft]
Carbon steel frame, outer Mongolian cold-rolled steel plate, base layer anti-rust paint, putty, external spray special car paint. The interior of the cabin body is made of glass fiber reinforced plastic, LED lighting in the cabin, and aluminum checkered board on the fl
