Customized FOTON AUMARK 4*2 LHD 220hp diesel 50,00-60,000 day old chick transported truck for sale, baby birds vehicle
Customized FOTON AUMARK 4*2 LHD 220hp diesel 50,00-60,000 day old chick transported truck for sale, FOTON Brand new Euro 2 livestock poultry baby birds van truck for sale
The baby chick trucks manufactured by Chengli Special Automobile Co., Ltd. adopts high quality Fiberglass Reinforced Plastic (FRP) for exterior and interior layer, and the middle insulation layer with 80mm PU foam sheets.
And we can customized the day old chick trucks, installed with cooling system, heating system, Ventilation system, windows and fans, etc. More information, please feel free to contact with Ms. Anita.
Truck for transported day old chick is a kind of special insulation van truck for transporting day old chickens and eggs, etc. It is suitable for large chick farms, etc.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of van truck in China. With many years’ development, Chengli Special Automobile Co., Ltd. could supply refrigerated truck, insualtion body van box, cargo van truck, baby chick transported truck, etc. And our CLW brand van truck have been exported to many countries all over the world. More information, please feel free to contact with Ms. Anita.
If you're interested in our day old chick truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: 0086 13329899995.
Website: www.trucksinchina.com
FOTON AUMARK 4*2 LHD 220HP diesel day birds transported vehicle, adopts high quality FOTON AUMARK 2200mm RHD one row and a half driver cab, 5150mm wheelbase, YC6J220-33 162KW/220hp diesel Euro 2 engine, 8 speed manual gearbox, 5.5tons front axle/10tons rear axle, 11R22.5 rail tires, air cut braking, air conditioner, power steering ,etc.
The technical parameters of upper part for FOTON AUMARK day old chicks transported truck as below
The cold van body dimension of FOTON AUMARK RHD day old chicks transported carrier is 6670×2300×2400 (mm). The interior and exterior of the van box body with fiber reinforced plastics(FRP), and the middle insulation layers of 80mm thickness PU foam. There are sliding windows and waterproof blind-windows. The air will be from the van body floor ventilation
Left and right sides of the van body are with 12 sets 40*40 Mesh Plates for the cold air from the reefer. There are several 320*320 electronic ventilator fans mounted on the truck top and the rear door plate. Folding Shelves are for the two sides van body. Both Two sides of the van body with 5 blind-windows; while top mounted sky-window. Three lines of ventilator Air Ducts mounted on the van floor. The reefer choose high quality China made engine-powered refrigerator( the lowest temperature inside the cold room box up to -10℃, adjusted at the driver cab). The heating system is selective.
More pictures of FOTON AUMARK 60,000 day old chick van truck as below.
HOT SALE!FOTON AUMARK RHD 60,000 day old chick transported truck
Main technical parameters of FOTON AUMARK RHD 60,000 day old chick transported truck manufactured by Chengli Special Automobile Co., Ltd. is as below.
| Product name | Foton aumark 4*2 LHD day old chick transported truck | ||
| Overall dimension(L*W*H)(mm) | 9100×2470×3760 | Chick van box dimension(L*W*H)mm | 6670×2300×2400 (mm). |
| Drive type | 4*2 LHD | Total mass | 15795 |
| Gearbox | 8 speed transmission, manual | Tyre specification | 9.00R20 rail tyres *6+1 |
| Power steering | Yes | Front/rear axle | 5.5tons front axle/10tons rear axle |
| Air cut braking | Yes | Driver cab | Foton Aumark 2200mm one row and a half driver cab with air conditioner |
| Engine | YC6J240-33 | Emission standard | Euro 2 |
| Rater power | 176KW/240hp | Displacement (ml) | 7255 |
Main technical parameters of day old chick van body
| Performance and consumption | |||
| Heating system | Watering system | Without, client choose to install | |
| Cooling system | One refrigerated reefer | China made high quality vehicle-powered refrigerated reefer( the lowest temperature inside the cold room box up to -10℃, adjusted at the driver cab) | |
| Ventilation system | Air duct installed on the floor for air flow | three line as the pictures show | |
| Cold air ducts on the two sides of the van body | two cold air ducts for the refrigerated reefer | ||
| Blind windows | 5 sets of blind windows for the left and right van sides (as the pictures show); two bigger water-proof blind window at the front van plate. Blind Windows: 5*2+2=12 |
||
| electronic ventilator fans | 1, 4 sets of electronic ventilator fans with sliding doors for the rear plate door; 5*2 sets of electronic ventilator fans for van top Electronic fans: 4+5*2=14 |
||
| Sky-window | Top mounted sky windows*4 Sky-windows: 4*1=2 | ||
| Dimension | |||
| Chick van box body | Length | 6670mm | |
| Width | 2300mm | ||
| Height | 2400mm | ||
| Refrigerated van box | Exterior and interior with FRP( fiber reinforced plastic), and the middle with 80mm PU slices; Aluminum-patterned baseplate; |
||
