Good price JMC 23m working height telescopic type aerial working platform truck for sale, truck mounted aerial platform
CLW telescopic boom aerial operating vehicle has operating heights of 12 meters, 14 meters, 16 meters, 18 meters, 20 meters, 21 meters, 28 meters, 29 meters, 45 meters, telescopic working boom, large outrigger span, stability Good, can be operated simultaneously or separately, safe and reliable, compact structure, convenient operation, fast lifting speed, high work efficiency. It is flexible and can work flexibly in tight high-rise buildings. It is the leader of aerial work vehicles and leads the new trend of the industry. It is widely used in installation, maintenance and climbing operations in such industries as municipal administration, electric power, street lights, advertising, communications, photography, gardening, shipbuilding, transportation, docks, airports and ports, emergency rescue, and large industrial and mining enterprises.
JMC brand 4*2 LHD 23m working height telescopic aerial working platform truck adopts JMC brand single row driver cab, truck chassis: JX1041TG26, 115hp diesel Euro Ⅵ engine, 3360mm wheelbase, 7.00R16 rail tires, 5 speed manual gearbox, oil cut braking, air conditioner, power steering, etc.
The working height is 23 meters with 4 sections arm, working arm with BS960E high strengthen steel material.
The telescopic truck mounted aerial working platform is with four hydraulic telescopic legs (up and down extension and horizontal extension), a total of 8* oil cylinders, the legs are front V and rear H type, emergency pump, lifting bucket 360 degrees Rotation, wireless remote control, and others are prepared according to factory standards.
If you're interested in our telescopic aerial working platform truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: 0086 13329899995
Website: www.trucksinchina.com
More pictures of 23m working height JMC brand telescopic aerial working platform truck is as below.
HOT SALE! JMC brand 23m telescopic aerial working platform truck for sale
main technical parameters of JMC brand telescopic aerial working platform truck for sale
| Item | Name | Specification/model |
| 1 | Truck name | JMC brand telescopic aerial working platform truck for sale |
| 2 | Truck model | CLW5046JGKJ6 |
| 3 | Chassis model | JX |
| 4 | Working height | 23M |
| 5 | Working technical parameters |
platform ground height≥21.3m platform max working range: 13m Flatform working height at the max working range: ≥3.5m Plafrom max working Angle of Tilt: 75° Rated mass of the working bucket: 200kg |
| Outriggers |
Type: Front V + rear H type, Individually control Outriggers nos. : 4 Control: Individually control or Linkage control Transverse Span of front outriggers: 4170mm gradient:120° Transverse Span of rear outriggers: 3930mm |
|
| Main operation |
Operation positio: revolving stage,teleoperation, displaying screen operation, etc. three modes Control type:ZYK bus control system, electro-hydraulic proportional control system, which realizing step-less speed regulation |
|
| 6 | Coaming and platform | Stainless steel fence and Non-slip platform |
| 7 | Boom construction mode |
four-section six-sided working arm,Synchronous telescoping, with BS960 high strengthen steel material manufactured. |
| 8 | Rotator device | Bidirectional 360°continuous rotation, lifting bucket 360°rotation |
| 9 | Engine model |
JX4D30B6H 85KW JX4D30D6H 85KW diesel engine |
| 10 | Overall dimension(L*W*H) | 5995×2250×3300 |
| 11 | Total mass | 4495kg |
| 12 | Curb mass | 4365kg |
| 13 | wheelbase | 3360mm |
