30tons 13.5m length Independent refrigeration unit refrigerated semi-hanging trailer, refrigerated container trailer
30tons capacity 13.5m length Independent refrigeration unit Sandwich structure refrigerated semi-hanging trailer, refrigerated container semitrailer for sale
Main parts and Fuction of CLW brand refriggerated van semitrailer is as below.
2. refrigeration units and inside temperature recorder
3. special components: meat hooks, aluminum rails, ventilation slots and other attachments.
We use a refrigerator to control the temperature of the cargo truck, user can set the temperature as they want. The lowest is down to Minus 18 degrees Celsius(-18 degree). This temperature can transport the frozen meat, ice cream, etc.
For temperature like 0 to 4 degree, we can transport vegetables, fruits, fresh meat, milk, yogurt, etc.
Also, you can set it to 0 to 10 degree to transport fish, crab, or any other sea foods.
New manufactured refrigerated van semitrailer is with the model of CLW9401XLC. And the overall dimension(L*W*H) is 13500x2600x3995 (mm); while the dimension(L*W*H) of the refrigerated container semitrailer is 13300X2400X2300(mm). High quality new processed refrigerated van body is with interior and exterior of high quality glass fiber-reinforced plastic (FRP). And the middle layer is with high quality 100mm thickness PU FOAM material. One side door(left or right is ok). The floor base adopts high quality aluainum alloy air trunking. Equipped with high quality Chinamade or USA Brand CARRIER independent self-powered reefer unit(the lowest temperature is up to -15 ℃).
The driving part of this CLW brand refrigerated container semitrailer is as below.
1, 13TONS FUWA axles*3,
2, 12R22.5 tires*12,
3, 28T outriggers.
If you're interested in our refrigerated truck, please send email to truck0011@163.com or talk to Anita by Whatsapp: 0086 13329899995.
Website: www.trucksinchina.com
More pictures of CLW brand 13.5m 30T refrigerated container semitrailer manufactured by Chengli Special Automobile Co., Ltd. is as below.
Main technical parameters of CLW brand 13.3m refrigerated container semitrailer manufactured by Chengli Special Automobile Co., Ltd. is as below.
| Main technical parameters | |||
| Product name | CLW9401XLC refrigerated container semitrailer for sale | ||
| Total mass(Kg) | 40000 | Overall dimension(L*W*H)(mm) | 13500×2600×3995 |
| Rated mass(Kg) | 29600 |
Van dimension (L*W*H)(mm) |
13000×2400×2300 |
| Curb mass(Kg) | 10400 | Wheelbase(mm) | 7350+1310+1310 |
| Approach/departure angle(°) | -/12 | Tire specification | 12R22.5 12PR*12 |
| Steel spring | -/8/8/8 | Tires nos. | 12 |
| Axle load(Kg) | -/24000(triples axles) | Axle nos. | 3 |
| Front tread(mm) | - | Rear tread(mm) | 1840/1840/1840 |
