Insulated Waterproof Techo Plastic Roof Tile For Factory Building Cover Workshop
Insulated Waterproof Popular Techo Plastic Roof Tile For Factory Building Cover Workshop
Product Description:
First layer:weather resistant resin is selected as the top layer material to block the solar ultraviolet radiation and reduce the coefficient of heat conductivity. It provides our UPVC roofing material with great durability and chemical corrosion resistance;
Second layer: the middle layer is a special foam structure with heat and sound insulation performances.
Third layer: the bottom layer of our heat insulated UPVC roof sheet adopts modified PVC material to offer optimum strength and rigidity.
Features:
1.Excellent heat resistant and Anti-corrosive
2. The variety of colors and patterns
3. High intensity, resist erosion, anti aging
4. Fireproof, waterproof, environmental friendly
5. Easy setting and cleaning
Applications:
High-grade workshop, steel structure workshop, warehouse, farmers' market, market passage, carport and other high-grade roofing materials. Especially in corrosive chemical plants, smelters, ceramics factory, soy sauce factory, fertilizer factory, printing and dyeing factory, organic solvent factory, acid, alkali and other corrosive factories.
|
Seaside Villa Project |
Resorts Project |
Chemical Factory Side Panel |
|
Parking Port Cover |
Pavillion And Villa Roof |
Organic Solvent Factory |
Technical Parameters:
|
Property |
Value |
|---|---|
|
Heat Reducing Roof Tiles |
Yes |
| Thermal Protection Roof Tiles | Yes |
| Heat Resistant Roof Tiles | Yes |
| Soundproof | Yes |
| Wind-resistant | Yes |
| Material | PVC, APVC, UPVC etc |
| Anti-freeze | Yes |
| Corrosion resistant | Yes |
| Anti-UV | Yes |
| Fading-resistant | Yes |
| Shape | Corrugated and trapezoidal |
Installation:
1. The thickness of the pvc roof tiles is ≤ 1.3mm to use the purling space ≤ 600mm. The circular arch roof to use for the purling space ≤ 700mm. The thickness between 1.3 mm to 1.8 mm of the tiles need to use for purling space ≤ 700mm. The arched back roof to be ≤ 800mm. The thickness 1.8mm to 3mm of roof sheet to use for the purling space as ≤ 800mm and circular arch style to use purling space ≤ 900mm.
2. The installation of the corrugated pvc roof sheet have to cover two pitch of the sheet aera on the width and the trapezium pvc roof sheet to cover one pitch on the width and to cover > 250mm on the length.
3. If use tapping screw that need to drill a hole with ratio 2-3 mm first.
