Roofing Material 3.0mm Plastic Roof Tiles Heat Proof Corrugated Roofing Sheet
Roofing Material 3.0mm Plastic Roof Tiles Heat Proof Corrugated Roofing Sheet
UPVC Roof Sheets is a once mounding energy-efficient roofing material. It is light in weight, rich in color, with better performance in water proof. It is easy to install in construction, low in price, thus it is an ideal substitute for asbestos tile, glass tile, cement tile, color steel tile.
Production Descripton:
1: Thermal insulation, noise insulation, fireproof waterproof.
2: Containing no volatile organic compounds, pure green environment-friendly building materials.
3: Easy for installation, construction, and it can be used with a variety of materials and excellent processing performance, nailing, sawing.
4: Rich in color, luminous like mirror, acid, alkali resistance, pollution, and do not fade.
Technology:
The product adopts ABA 3 layered co-extrusion technology under one-off processing, both sides (A) ismodified anti-weathering and anti-corrosion PVC resin, the middle layer(B) modified opaque PVC resin with superb rigidity and toughness . it's the upgrade version of single layer PVC corrugated roofing tile.
Container load:
| Thickness | SQ.M./20 FCL (21 Tons) | SQ.M./20 FCL (26 Tons) |
| 1.5 mm | 7200 m2 | 9000 m2 |
| 1.8 mm | 6100 m2 | 7600 m2 |
| 2.0 mm | 5500 m2 | 6800 m2 |
| 2.5 mm | 4300 m2 | 5400 m2 |
| 3.0 mm | 3600 m2 | 4500 m2 |
Test Report:
| Heat-Resistance |
(72°c,6h)no deformation, no viscousness |
High-low temperature change | ±0.11% |
| Cold-Resistance | (-40 °c,6h) no crack in suirface | Fire-protection | Class B1 |
| Bending capability | 25mm | Vicat softening temperature | ≥75°c |
| Flexural load | 800N, no crack | Water absorption rate | ≤0.05% |
| Flexural strength | 72MPa | Nail force | ≥46N |
| Tensile strength | 30MPa | Chemical resistance properties | No reaction in salt, alkali(≤60%) |
FAQ:
1. How to install the PVC Roof, Corrugated Roofing Sheet?
Overlap, on the vertical direction overlap 150-200mm, on the horizontal direction overlap one wave.
2.What is the temerature limited of the environment that your roof can be used?
Temperature range: From Minus 35 degree to 72 degree
3.What color can you produce?
White, blue, brick red, green, grey etc, same as our color swatch. If you need special color, please provide sample.
4.Does you charge for the samples?
According to our company policy, we just sent free samples to customers while the customers bear the freight fees.
5. Can you produce according to customers'design?
Sure, we are professional manufacturer,OEM are welcome . But the beginning you need pay the mould open fees,after certain quantity, the open mould fees will be returned as product.
Supply high quality roof material and best solution !
