Impact Resistant Plastic Corrugated Roofing Sheets For Bus Station Villa Park
Impact Resistant Speical Plastic Corrugated Roofing Sheets For Bus Station Villa Park
Specification of ASA Little Blue Tiles
|
Thickness
|
2.3mm~3.0mm | ||
|
Material
|
ASA + PVC + PCC | ||
|
Length
|
customized(must be according to the times of 219mm) | ||
|
Width
|
1120MM | ||
|
Effect Width
|
960MM | ||
|
Distance between wave
|
250mm | ||
|
Height of Wave
|
40mm | ||
|
Wave Width
|
160mm | ||
|
Purlin space
|
800~1120mm | ||
|
Weight
|
2.5mm: 5.0±0.1kg/m2 | 2.8mm: 5.5±0.1kg/m2 | 3.0mm: 6.0±0.1kg/m2 |
|
Container Load capacity
|
Thickness | SQ.M./20 FCL (21 Tons) | SQ.M./40 FCL (26 Tons) |
| 2.5mm | 4000 | 5000 | |
| 2.8mm | 3500 | 4300 | |
| 3.0mm | 3300 | 4100 | |
Features of ASA Little Blue Tiles
1. Color stable ( No fade in 10 years);
2. Excellent load-carrying ability ( 150KG of load is applied);
3. Good sound insulation ( Under the noise of rainstorm and strong wind);
4. Strong fire resistance ( Its fireproofing performance is > class B1);
5. Excellent corrosion resistance ( Especially use in places where acid rain often falls and coastal areas);
6. Good impact resistance and cold resistance (Not crack after a 1KG steel ball falls on 3 meters hight);
7. Good self-cleaning performance;
8. Dimension stability ( The expansion cosfficient is 4.95*10-5 mm/mm/°C);
9. Extraordinary insulation;
10. Excellent waterproof performance;
11. Green and environment friendly;
12. Extrordinary heat preservation and heat insulation ( 2~3 celsius degree lower than steel tile);
13. Fast and easy installation ( Light weight ).
Applications of ASA Little BlueTiles
Used for flat slope modification project, villas, private house, mobile housing, garden pavilions, ancient architecture and other roof areas.
Our factory has rich experience in PVC plastic tile product manufacture and we are a professional supplier of ASA synthetic resin tile, Anti-Corrosion APVC roof sheet, Heat Insulated UPVC roof sheet , PVC corrugated roof sheet , PVC flat sheet , FRP lighting roof sheet , Transparent PC roof sheet , PVC water gutter series and accessories.
| residentia | bus station |
| temporary housing | train station |
| stage design | Building decoration |
Why Choose Us
1. More than 10 years experiences in trading and producing
2. Abundant financial strength
3. Good reputation
4. Excellent technique control
5. Rigorous testing process
6. Professional management team
7. With competitive price
8. Meet customers' needs by reprocessing
9. High quality after-sales service
10. Timely delivery time
Technical Information
- Heat Distortion Temperature - Under 70℃
- Fire Resistance - B1 Grade
- Horizontal Burning - FH-1
- Fade Lasting - △E≤5
- UV Agent - 27% UV Light
- Aging Resistance - Passing 25 Years
- Softening Temperature - More than 75.2℃
