Resistance To Impact PVC Plastic Spanish Roof Tiles Prices Waterproof
Price:
Negotiation
MOQ:
1000 m2
Delivery Time:
Within 10 Days After The Payment
Brand:
Yiquan
Product Description
Resistance To Impact PVC Roof Tile Wholesale Waterproof Plastic Spanish Roof Panels
SPECIFICATION:
| Brand | YIQUAN |
| Item | ASA-PVC Corrugated Roof Sheet |
| Origin | China |
| Main Material | UPVC |
| Coating | ASA Embossed |
| Coating Material | ASA |
| Overall Width | 1130 mm / 1360 mm |
| Effective wide | 1050 mm / 1240 mm |
| Length | Customized |
| Wave Distance | 210 mm / 209 mm |
| Wave Height | 26 mm / 27 mm |
| Color | Customized |
Colors choice:
Top layer:white, blue, green, beige( light yellow ), terra-cotta ,grey or customized.
Bottom layer: white or customized
Load Capacity:
| Container Load capacity | Thickness | SQ.M./20 FCL (21 Tons) | SQ.M./20 FCL (26 Tons) |
| 1.0mm | 11000 m2 | 13600 m2 | |
| 1.5mm | 7200 m2 | 9000 m2 | |
| 1.8mm | 6100 m2 | 7600 m2 | |
| 2.0mm | 5500 m2 | 6800 m2 | |
| 2.5mm | 4300 m2 | 5400 m2 | |
| 3.0mm | 3600 m2 | 4500 m2 |
Installation:
| PVC tile installation should choose appropriate purlin spacing to prevent deformation cracking. |
| Water leakage ,specific reference to the following: |
| •The thickness of the pvc roof tiles is≤1.3mm to use the purling space≤600mm. |
| the circular arch roof to use for the purling space≤700mm.the thickness between |
| 1.3mm to 1.8mm of the tiles need to use for purling space ≤700mm. |
| the arched back roof to be ≤800mm.the thickness 1.8mm to 3mm of roof sheet to |
| use for the purling space as ≤800mm and circular arch style to use purling space≤900mm |
| •The installation of the corrugated pvc roof sheet have to cover two pitch of the sheet area on |
| the width and the trapezium pvc roof sheet to cover one pitch on the width and to cover >250mm on the length. |
| •If use tapping screw that need to drill a hole with ratio 2-3mm first. |
