Fire Resistance PVC Roof Tiles Sheet For Warehouse , Customize Length
Price:
negociated
MOQ:
1000 sqm
Delivery Time:
7 days after the downpayment
Brand:
Yiquan
Product Description
Pvc Plastic Roof Sheet for warehouse/PVC Roofing Sheet building material/UPVC Roundwave Roof Tile
Features:
2. Loading bearing: It can load 150 kg per square meter evenly;
3. Light weight: 1.92 to 5.7 kg/square meter;
4. Water resistance: 100%;
5. Fire resistance: Self-extinguish off fire;
6. Anti corrosion;
7. Impact resistance and low temperature resistance;
8. Sound and heat insulation;
9. Small Thermal expansivity;
10. Environmental protection and energy conservation;
11. Easy to install
1.save cost
Installation :
| PVC tile installation should choose appropriate purlin spacing to prevent deformation cracking. |
| Water leakage ,specific reference to the following: |
| •The thickness of the pvc roof tiles is≤1.3mm to use the purling space≤600mm. |
| the circular arch roof to use for the purling space≤700mm.the thickness between |
| 1.3mm to 1.8mm of the tiles need to use for purling space ≤700mm. |
| the arched back roof to be ≤800mm.the thickness 1.8mm to 3mm of roof sheet to |
| use for the purling space as ≤800mm and circular arch style to use purling space≤900mm |
|
•The installation of the corrugated pvc roof sheet have to cover two pitch of the sheet area on the width and the trapezium pvc roof sheet to cover one pitch on the width and to cover >250mm |
| on the length. |
| •If use tapping screw that need to drill a hole with ratio 2-3mm first. |
