1.6 Ton Three Wheel Electric Forklift Truck With Dual Front Driving Wheel

1.6 ton three wheel electric forklift truck with dual front driving wheel​


Quick Details:


Model: Three wheel electric forklift truck CPD20SA-16

​​​Capacity: 1600kg

Lift height: 3000-6200mm

Aisle width for pallets 1000*1200 crossways: 3120mm

Aisle width for pallets 800*1200 lengthways: 3220mm

Turning radius: 1552mm

Travel speed, laden/unladen: 14km/h

Battery: 48V420(490)AH



Advantages:

• Germany imported driving axle.​​

• The United states imported AC control system CURTIS with sensitive reaction.

• Imported multifunctional liquid crystal instrument has intelligent display for fault code, battery status, forklift running information.

• AC driving motor: compact construe, high performance, regenerative braking.

• Top-ranking running speed, loading speed and grade ability.

• Running speed: unload 15km/h, load 14km/h

• Lifting speed: unload 450mm/s, load 290mm/s

• Grade ability: unload 20%, load 15%

• Three running modes to choose according to different needs: low speed, moderate speed and high speed.

• Wet disk brake can make the forklift break stably, ensures high durability and safety.

• Lateral turning radius is only 1552mm and minimum right angle stacking aisle is only 3220mm.

• Convenience in maintenance.

• Easy maintained controller and steering potentionmeter.

• Maintenance free wet disk brake.

• Different from traditional Drum braking system, this system doesn't need to maintain extensively and regularly except for oil change, so it reduces maintenance cost.

• Lifting and driving AC motors without carbon brush almost has no need to maintain, which greatly reduce maintenance cost. And they all adopt external encoder, so the maintenance and service is more convenient.
