CS Centrifugal Spheronizer

Description:

WG Centrifugal Spheronizer is the main equipment for granules break down and spheronization processes. It consists of the hopper, tooth rotates disc, discharge device, drive device, frame, pneumatic system and control system. The granule extrudate is broken by the tooth of the fast rotating disc into equal length short-cylinder segments. The extrudate is then rounded to pellets under tooth push force, centrifugal force and friction between container wall and pellets. It is widely used for pelletizing in pharmaceutical, food and chemical industry.

Features:

Compact design, nice appearance, easy to dismounting and clean.
Can use after extruder, rotary granulator and oscillating granulator.
Finished pellet has good roundness, smooth surface and uniform distribution of particle size.
Safe interlock protection to prevent operator, product and equipment.
User-friendly color touchscreen operation, PLC controller, orthogonal tooth plate.

Options:

Radial tooth plate with anti-metal coating or wear-resisting coating function.
Inducing air dehumidification.
Data printers.

Specifications:



Model	WG-500	WG-700	WG-1000
Capacity [kg/h]	1~3	3~8	10~25
Process Time [min/batch]	3~6
Materials Yield [%]	≥ 98
Power [kW]	500	700	1000
Plate Diameter [mm]	500	700	1000
Plate Rotate Speed [rpm]	110~1100	90~900	65~650
Power of Rotate Plate [kW]	4	5.5	7.5
Power of Blower Motor [kW]	1.1	1.3	4
Compressed Air Pressure [MPa]	0.4~0.6
Compressed Air Consumption [m³/min]	0.2
Dimensions [mm]	1100x800x1310	1510x950x1400	1800x1145x1530



Product Photo:
