0.9kw Pharmaceutical Cotton Inserter Machine With Photo Electronic Locating System
SM-2 Automatic Cotton-inserting Cotton Sliver Inserters Bottle Packing Machine Inserting Layer Insulating Protection
SM-2 Automatic High-speed Cotton Inserters
Description:
The equipment adopts the high-precision photo electronic locating system to automatically break the cotton sliver and insert in the bottle to ensure accuracy of position.
Self-diagnose errors and stop working to make alarm at errors and missing bottles as well as change cotton sliver.
Adopt pneumatic cotton-inserting technology to avoid pollution of materials.
Features:
Wide applicability
Can be used for round, flat round, square, flat square bottles made of different material.
Detection function
Self-diagnose errors and stop working to make alarm at errors and missing bottles as well as change cotton sliver.
Patented cotton-insert technology
Using pneumatic cotton-insert technology to avoid pollution of materials.
Clean
Collect dust by negative pressure to ensure the clean working environment.
Specifications:
| Model | SM-2 |
| Applicable for [ml] |
50-500 (Inner diameter of the of bottle neck must be more than 22mm) |
| Applicable cottons | Medical grade coil cottons of diameter Φ30 (bulk), well-proportioned. |
| Capacity [BPM] |
60-100 (subject to the type and size of the bottle) |
| Power supply | 220V/50Hz |
| Power [kw] | 0.9 |
| Air supply pressure [Mpa] | 0.6 |
| Air supply [l/min] | 20 |
| Size [mm] |
1600*750*1400 (without the feeding part) |
| Weight [kg] | 200 |
Picture Photo:
