High Performance Bottle Packaging Line Pneumatic Paper Inserting Machine 260kg
TS-2 Automatic High-speed Paper Inserters Bottle Packing Machine Folding Inserting Insert Leaflet Instruction Book
TS-2 Automatic High-speed Paper Inserters
Description:
The equipment adopts the high-precision photo electronic locating system to automatically cut the paper and insert it in the bottle to ensure accuracy of position.
Self-diagnose errors and stop working to make alarm at errors and missing bottles as well as change paper roll.
Adopt pneumatic paper-inserting technology to avoid pollution of materials.
Features:
Wide applicability
Can be used for round, flat round, square, flat square bottles made of different material.
Detection function
Self-diagnose errors and stop working to make alarm at errors and missing bottles as well as change the paper roll.
Patented paper-insert technology
Using pneumatic paper-insert technology to avoid pollution of materials.
Specifications:
| Model | TS-2 |
| Applicable for [ml] |
50-500 ( Inner diameter of the bottle neck is not less than 17mm) |
| Capacity [BPM] |
60-100 (subject to the type and size of the bottle) |
| Power supply | 220V/50Hz |
| Power [kw] | 0.75 |
| Air supply pressure [Mpa] | 0.6 |
| Air supply [l/min] | 20 |
| Size [mm] |
1600*750*1400 (without the feeding part) |
| Weight [kg] | 260 |
Picture Photo:
