Power Saving Bottle Packaging Line Horizontal Labeling Machine For Round Bottles Tubes
S-500 Type Horizontal Labeling Machine
Description:
Suitable for all specifications of small round bottles horizontal labeling.
Horizontal bottles feeding. Easy operation, low rate of broken bottles (less than one
over two hundred thousand).
Screw spacing bottle, bottle spacing is uniform and synchronize with conveyor belt, do not lack, not break bottles.
Use imported well-known brand servo motor, ensuring high speed, precision, and stability.
High-speed sponge wheel rolling on stick labels, which of good buffer and wearability.
High labeling speed and precision, labeling accuracy ± 0.5 mm.
Feature:
Horizontal feed
Screw bottle spacing
High speed label feed
Specifications:
| Model | S-500 |
| Bottle diameter [mm] | 10-30 |
| Labeling speed [bottle/min] | 0-500 |
| Labeling accuracy [mm] | ±0.5 |
| Rote of broken bottles | 1/200000 |
| Label length [mm] | 20-95 |
| Total power [kW] | 2.0 |
| Electrical source | 220V, 50Hz |
| Air source [MPa] | 0.5 |
| Machine dimension [mm] | 2650*1310*1640 |
| Machine weight [kg] | 380 |
Photo:
