Top Driven Pharmaceutical Milling Equipment Conical Mill Chamber Frequency Control Rotary Knife
FZB Top-driven Cone Mill Conical Mill Chamber Frequency Control, Rotary Knife,
Description:
FZB series cone mill is widely used in medical, food and fine chemical industry. In the pharmaceutical industry, normally used for milling of raw material, granulating of dry granule and recycling of unqualified tablets The required mesh size was made through this machine and then come to the blending and tablet pressing. It has the outstanding features of low noise&dust, easy washing, particle easy controlling, etc.
Features:
Thoroughly solving the tough problem of material contaminated by the debris of worn sieve mesh in a pendulum-type granulating machine
The unique patented shaft sealing technology ensures no leakage of lubrication oil.
Easy to control granularity
No retention dead corner, no material overheating
Less dust, no vibration, low noise
High efficiency, energy saving, large production capacity
Attractive appearance, easy to clean.
Options:
Ex-proof design
Additional size sieves
Specifications:
|
Model |
FZB-700 |
|
Milling capacity [kg/h] |
70~700 |
|
Milling fineness [mesh] |
6~80 |
|
Main shaft speed [rpm] |
300~2800 |
|
Motor power [kw] |
3 |
|
Discharge height [mm] |
700 |
Product Photos:
