0.5-0.8G Fill Volume Pharma Packaging Machines Stick Packing , Screw Filling
0.5-0.8G Fill Volume Pharmaceutical Packaging Equipment Stick Packing, Screw Filling
Description:
The machine is suitable for packaging powdered materials in food, chemical, pharmaceutical and other industries, such as packaging of seasonings.
The machine includes automatic stick forming, metering, filling, sealing, cutting, output counting and batch number printing functions. And it adopts advanced microcomputer controller to drive stepper motor control stick length and mark positioning. The performance of the machine is stable, easy to adjust, accurate in detection, and minimum error under intelligent control.
The machine can add attachments for optional date printing, beat discharging, easy tear and other functions.
Features:
Back seal sachet, round corner and easy to tear.
Automatic sachet forming, screw feeding, filling, sealing, cutting, output sachet quantity counting, code embossing, and other functions.
The computer controls the stepping motor to pull the bag, no need to adjust the empty walk, saving time and film.
Stable performance, accurate detection, increase the corresponding accessories to complete the date printing, easy to tear and other functions.
Specifications:
| Model | HT-60YBF |
| Capacity [sticks/min] | 20-60 |
| Sealing method | Back sealing |
| Filling range [g] | 0.5-0.8 g |
| Filling precision | ± 0.05 g for 0.8 g |
| Stick size [mm] | L:50-160 W:20-130 |
| Power [kw] | 1.5 |
| Power supply | 230V 50Hz |
| Weight [kg] | 450 |
| Dimension [mm] | 990*870*1880 |
