China 4inch 6Inch 4H-N 500mm 350um SIC wafer Silicon Carbide sic Substrate Prime Dummy Grade for sale

4inch 6Inch 4H-N 500mm 350um SIC wafer Silicon Carbide sic Substrate Prime Dummy Grade

Price Negotiable
Price: by case by FOB
MOQ: 1pcs
Delivery Time: within 40days
Brand: zmsh
Product Description

4inch 6Inch 4H-N 500mm 350um SIC wafer Silicon Carbide sic Substrate Prime Dummy Grade

6inch 4H-N 500mm 350um sic substrate wafer for powder device



6 inch diameter, Silicon Carbide (SiC) Substrate Specification
Grade Zero MPD Grade Production Grade Research Grade Dummy Grade
Diameter 150.0 mm±0.2mm
ThicknessΔ 350 μm±25μm or 500±25un
Wafer Orientation Off axis : 4.0° toward< 1120> ±0.5° for 4H-N On axis : <0001>±0.5° for 6H-SI/4H-SI
Primary Flat {10-10}±5.0°
Primary Flat Length 47.5 mm±2.5 mm
Edge exclusion 3 mm
TTV/Bow /Warp ≤15μm /≤40μm /≤60μm
Micropipe Density ≤1 cm-2 ≤5 cm-2 ≤15 cm-2 ≤100 cm-2
Resistivity 4H-N 0.015~0.028 Ω·cm
4/6H-SI ≥1E5 Ω·cm
Roughness Polish Ra≤1 nm
CMP Ra≤0.5 nm
Cracks by high intensity light None 1 allowed, ≤2 mm Cumulative length ≤ 10mm, single length≤2mm
Hex Plates by high intensity light Cumulative area ≤1% Cumulative area ≤2% Cumulative area ≤5%
Polytype Areas by high intensity light None Cumulative area≤2% Cumulative area≤5%
Scratches by high intensity light 3 scratches to 1×wafer diameter cumulative length 5 scratches to 1×wafer diameter cumulative length 5 scratches to 1×wafer diameter cumulative length
Edge chip None 3 allowed, ≤0.5 mm each 5 allowed, ≤1 mm each
Contamination by high intensity light None
