China Howo Dump Truck 6x4 euro 2 10 Wheel Dump Trucks 336hp 40 Ton Used Sinotruk Left/Right-hand Drive Tipper Trucks for sale

Howo Dump Truck 6x4 euro 2 10 Wheel Dump Trucks 336hp 40 Ton Used Sinotruk Left/Right-hand Drive Tipper Trucks

Name: Howo Dump Truck 6x4 euro 2 10 Wheel Dump Trucks 336hp 40 Ton Used Sinotruk Left/Right-hand Drive Tipper Trucks
Brand: Jinan Heavy Truck Import & Export Co., Ltd.

Price Negotiable

Price: USD23100-25410

MOQ: 1 UNIT

Delivery Time: 45 Work days

Brand: Howo

Product Description

Howo Dump Truck 6x4 euro 2 10 Wheel Dump Trucks 336hp 40 Ton Used Sinotruk Left/Right-hand Drive Tipper Trucks

Model	ZZ3257V3847B1
Driver's Cab	HW76 extended cab, with one sleeper berth ,with air conditioner, air seat for driver. MP3
Engine	Model: WP12.400E201, Euro II emission standard, 4 stroke injection diesel engine, 6 cylinder in-line with water cooling, turbo-charging & inter cooling. Maximum output: 400PS (294kW) at 2100 rpm Maximum torque: 2060Nm at 1200-1500rpm Bore: 126mm Stroke: 155mm Displacement: 11.596L Brand: Weichai
Steering	Model: BOSCH Hydraulic steering with power assistance Left hand driving
Clutch	Φ430 Pull-type diaphragm spring clutch
Transmission	Model: HW19710, 10 forward and 2 reverse Manual type With transmission power take-off HW70 Max Torque: 1900N·M
Front Axle	Model: HF9 Drum brake system Rated loading capacity :9000kgs
Rear Axle	Model: MCP16ZG Capacity: 16000kgs Drum braking steering axle,self-adjusting arm Speed ratio:
Wheelbase	3800+1350 mm
Brake System	Type :Wabco braking system ABS 4S/4M Engine exhaust valve brake
Oil Tanker	300L aluminum alloy fuel tank
Tires	Types: 12.00R20 radial tire; 18PR 10 pcs, plus one pc spare tire
Bumper	Metal bumper
Dump body	560023001500mm, 8mm for bottom and 6 mm for side plate, rectangular box, Chinese brand front lifting cylinder, with integral fender, headlight cover.
Dimensions in mm	Front wheel track (mm): 2022 Rear wheel track (mm):1830 Overhang(front/rear) (mm):1500/1870 Overall Dimension (mm): 865025803450
Weight in kg	Dead weight (kg):13500 Gross vehicle weight (kg):25000

A dump truck, also known as a dumper truck or tipper truck, is used for transporting loose material such as sand, gravel, or demolition waste for construction. A typical dump truck is equipped with an open-box bed, which is hinged at the rear and equipped with hydraulic rams to lift the front, allowing the material in the bed to be deposited ("dumped") on the ground behind the truck at the site of delivery.

Types of Dump Trucks:

1. Standard Dump Truck

Design: It has a full truck chassis with the dump bed mounted onto the frame.
Functionality: The hydraulic ram system lifts the bed vertically to dump the load.

2. Articulated Dump Truck

Design: Consists of a hinge between the cab and the dump box, allowing for better maneuverability.
Functionality: Suitable for rough terrain due to its high flexibility.

3. Transfer Dump Truck

Design: A standard dump truck that pulls a separate trailer with a movable cargo container.
Functionality: The trailer can be used to carry additional material, increasing load capacity.

4. Side Dump Truck

Design: The dump bed is mounted on the side of the truck.
Functionality: The bed tilts to the side to dump the load, providing rapid unloading.

5. Superdump Truck

Design: Equipped with a trailing axle that can be lifted when not in use.
Functionality: Can carry a larger load while adhering to road regulations.

6. Bottom Dump Truck

Design: The dump bed has a clam-shell gate at the bottom.
Functionality: Allows for controlled dumping of materials, often used for spreading materials evenly.

7. Double and Triple Trailer Bottom Dump Truck

Design: Consists of a tractor pulling a single trailer with the ability to dump material from the bottom.
Functionality: Designed for large-scale material transport.
