China Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering for sale

Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering

Name: Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering
Brand: Jinan Heavy Truck Import & Export Co., Ltd.

Price Negotiable

Price: USD23100-25410

MOQ: 1 UNIT

Delivery Time: 45 Work days

Brand: SINOTRUK

Product Description

Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering

Model	ZZ3257V3847B1
Driver's Cab	HW76 extended cab, with one sleeper berth ,with air conditioner, air seat for driver. MP3
Engine	Model: WP12.400E201, Euro II emission standard, 4 stroke injection diesel engine, 6 cylinder in-line with water cooling, turbo-charging & inter cooling. Maximum output: 400PS (294kW) at 2100 rpm Maximum torque: 2060Nm at 1200-1500rpm Bore: 126mm Stroke: 155mm Displacement: 11.596L Brand: Weichai
Steering	Model: BOSCH Hydraulic steering with power assistance Left hand driving
Clutch	Φ430 Pull-type diaphragm spring clutch
Transmission	Model: HW19710, 10 forward and 2 reverse Manual type With transmission power take-off HW70 Max Torque: 1900N·M
Front Axle	Model: HF9 Drum brake system Rated loading capacity :9000kgs
Rear Axle	Model: MCP16ZG Capacity: 16000kgs Drum braking steering axle,self-adjusting arm Speed ratio:
Wheelbase	3800+1350 mm
Brake System	Type :Wabco braking system ABS 4S/4M Engine exhaust valve brake
Oil Tanker	300L aluminum alloy fuel tank
Tires	Types: 12.00R20 radial tire; 18PR 10 pcs, plus one pc spare tire
Bumper	Metal bumper
Dump body	560023001500mm, 8mm for bottom and 6 mm for side plate, rectangular box, Chinese brand front lifting cylinder, with integral fender, headlight cover.
Dimensions in mm	Front wheel track (mm): 2022 Rear wheel track (mm):1830 Overhang(front/rear) (mm):1500/1870 Overall Dimension (mm): 865025803450
Weight in kg	Dead weight (kg):13500 Gross vehicle weight (kg):25000

A dump truck, also known as a dumper truck or tipper truck, is used for transporting loose material, such as sand, gravel, or demolition waste, for construction. Here are some key details:

Types of Dump Trucks

Standard Dump Truck
- Has a truck chassis with a dump body mounted to the frame.
- Equipped with a hydraulic ram to lift the front of the body, allowing material to be dumped out the back.
Articulated Dump Truck (ADT)
- Has a hinge between the cab and the dump box.
- Offers excellent maneuverability and is suited for rough terrain.
Transfer Dump Truck
- Standard dump truck pulling a separate trailer with a movable cargo container.
- Allows for a higher payload capacity.
Side Dump Truck
- Features a hydraulic system that tilts the dump body to the side to unload.
- Stable and can unload quickly.
Superdump Truck
- Standard dump truck with a trailing axle to increase load capacity.
- Can carry heavier loads and still comply with road regulations.

Key Features

Hydraulic System: Essential for lifting the dump body.
Durable Construction: Able to handle heavy and abrasive materials.
High Payload Capacity: Varies depending on the type and size of the truck.
Off-road Capabilities: Especially in articulated and superdump trucks.

Uses

Construction: Transporting materials like sand, gravel, and concrete.
Mining: Moving ore, coal, and other mined materials.
Landscaping: Hauling soil, mulch, and other landscaping materials.
Municipal: Snow removal, waste management, and other public works.

Considerations When Choosing a Dump Truck

Payload Capacity: Ensure the truck can handle the weight of the materials you need to transport.
Terrain: Choose a model suited for the environment in which it will operate.
Maintenance: Consider the ease of maintaining the hydraulic systems and other components.
Regulations: Ensure the truck complies with local road and safety regulations.
