chidong H16V190ZLC-3 marine engine parts radiator fan fuel line coupling assembly
Price:
1
MOQ:
1
Delivery Time:
11
Brand:
chidong
Product Description
| Series 600 marine diesel engines | ||||||
| Model | Rated Power(kw/hp) | Rated speed(r/min) | Specific fuel consumption(g/kw’h) | Specific oil consumption(g/kw’h) | Overall dimension L*B*H(mm) | Net weight(kg) |
| H12V190ZLC | 1580/2150 | 1450 | ≤200 | ≤1.0 | 3212*1597*2211 | 9500 |
| H12V190ZLC2 | 1500/2040 | 1500 | ≤200 | ≤1.0 | 3212*1597*2211 | 9500 |
| H12V190ZLC-1 | 1200/1630 | 1200 | ≤200 | ≤1.0 | 3212*1597*2211 | 9500 |
| H16V190ZLC1 | 2400/3200 | 1500 | ≤200 | ≤1.0 | 3525*2060*2331 | 13000 |
| H16V190ZLC | 2200/3000 | 1500 | ≤200 | ≤1.0 | 3525*2060*2331 | 13000 |
| H16V190ZLC-1 | 1650/2240 | 1200 | ≤200 | ≤1.0 | 3525*2060*2331 | 13000 |
| H8190ZLC | 1000/1360 | 1450 | ≤200 | ≤1.0 | 3349*1416*2225 | 8200 |
| H8190ZLC-1 | 830/1120 | 1200 | ≤200 | ≤1.0 | 3349*1416*2225 | 8200 |
| H8190ZLC-2 | 700/950 | 1000 | ≤200 | ≤1.0 | 3349*1416*2225 | 8200 |
| H8190ZLC-3 | 900/1225 | 1300 | ≤200 | ≤1.0 | 3349*1416*2225 | 8200 |
| Main technical data | ||||||
| No. and arrangement of cylinders:12,60.Vee | ||||||
| Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection | ||||||
| Bore:190mm | ||||||
| Stroke:215mm | ||||||
| Total displacement:73.15/48.77L | ||||||
| Compression ration:14.5:1 | ||||||
| Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel) | ||||||
| Starting method:Air motor or electric motor | ||||||
| Lubricating method:Pressure and splash lubrication |
|
