Reliable Operation Centrifugal Mud Pump Spare Parts Cast Iron Impeller
Cast Iron Impeller for Mission Centrifugal Pump / China Horizontal Centrifugal Pump Supplier
Introduction
Centrifugal pump is ideal corollary equipment to provide power for desander, desilter and jet mud mixer. It also can fill mud pump and replenish wellhead in drilling process. Most of its parts can be exchangeable. It has advantages of reliable operation, easy maintenance, little shaft seal leakage, and long service life.
TR Solid Control is a manufacturer of centrifugal pump. Our pump has API certificate. We supply top-quality centrifugal pump and best service.
How to select centrifugal pump?
- Firstly, determine how much capacity of the centrifugal sand pump, which equipment matched with centrifugal pump needs capacity. Generally the capacity of centrifugal pump we select should be a bit larger than capacity of its matched equipment. There is a valve on the centrifugal pump outlet for regulating flow rate it requires;
- Secondly, ensure how much lift the centrifugal pump needs. Selecting a centrifugal pump which has higher lift , since loss of pipeline is very large.
- Lastly, if using centrifugal pump for supplying mud to the desander and desilter, we must choose a lager capacity centrifugal pump. Because desander and desilter require very strict for the pressure. If the capacity of centrifugal pump is too small for supplying desander and desilter, its pressure is insufficient, thus affecting the working effect of desander and desilter.
Technical Data of TRSB Series Drilling Centrifugal Pump
| Model | Power | Flow | Lift(m) | Efficiency | NPSH | Electric |
| TRSB8×6-14J | 75KW | 320m3/h | 40m | 65% | 5 | 50HZ |
| TRSB8×6-12J | 355m3/h | 43m | 66% | 4.8 | 60HZ | |
| TRSB8×6-13J | 55KW | 290m3/h | 33m | 64% | 5.5 | 50HZ |
| TRSB6×5-12J | 196m3/h | 48m | 61% | 3 | 60HZ | |
| TRSB6×5-13J | 45KW | 180m3/h | 34m | 60% | 3 | 50HZ |
| TRSB5×4-14J | 149m3/h | 61m | 58% | 4.6 | 60HZ | |
| TRSB6×5-12J | 37KW | 160m3/h | 30m | 60% | 3 | 50HZ |
| TRSB5×4-12J | 112m3/h | 45m | 58% | 4.6 | 60HZ | |
| TRSB6×5-11J | 30KW | 120m3/h | 21m | 62% | 2.5 | 50HZ |
| TRSB5×4-12J | 112m3/h | 37m | 57% | 4.6 | 60HZ | |
| TRSB5×4-12J | 22KW | 90m3/h | 30m | 56% | 4.5 | 50HZ |
| TRSB5×4-10J | 105m3/h | 30m | 57% | 4.2 | 60HZ | |
| TRSB5x4-11J | 18.5KW | 90m3/h | 24m | 56% | 4.5 | 50HZ |
| TRSB4x3-12J | 55m3/h | 46m | 48% | 4 | 60HZ | |
| TRSB4x3-13J | 15KW | 50m3/h | 40m | 48% | 4.5 | 50HZ |
| TRSB4x3-11J | 54m3/h | 35m | 47% | 4 | 60HZ | |
| TRSB4x3-12J | 11KW | 45m3/h | 30m | 47% | 4 | 50HZ |
| TRSB3x2-12J | 28m3/h | 45m | 40% | 3.1 | 60HZ | |
| TRSB3x2-12J | 7.5KW | 45m3/h | 24m | 46% | 4 | 50HZ |
| TRSB3x2-11J | 25m3/h | 35m | 41% | 3.1 | 60HZ | |
| TRSB3x2-11J | 5.5KW | 20m3/h | 23m | 39% | 3 | 50HZ |
If you are searching good price spare parts which can be replaceable with Mission centrifugal pump, TR Solids Control is your good choice. Our pump spares have short delivery and high quality. Once you have any new requirement about this, we are welcome your inquiry!
Competitive Advantages
1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.
Company Tenet
Customer's satisfaction is the highest pursuit of TR Solids Control.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
