255100A1702AAAAA Gerotor Hydraulic Motor Danfoss White 11204730 WR Motor 255 Series
255100A1702AAAAA Danfoss White 11204730 WR Motor 255 series Replacement
Quick review:
Item #: 103-1091-012
Product Info
Alt Part #: 151-2473, 1512473, 255100A1702AAAAA, AEM100-2ST, AEM1002ST, TE0100AM110AAAB
Brand: Hanjiu Technology
255100A1702AAAAA
The WR Series motor incorporates the latest advances for smooth performance, efficiency and durability. It features an optimized Roller Stator geometry with seven precision rollers to eliminate sliding friction and provide rolling contact between the rotor and stator. This increases motor efficiency. A three-zone spool valve, integral check valves and a provision for a drain reduce pressure on internal seals to improve product life. A wide variety of mounting, shaft, motor displacement and porting options are available to meet all application needs.
|
Displacement: |
93 cubic centimetre per revolution |
| Mounting_Type: | 2 Bolt Std – 82.50 [3.248] Dia. X 3.05 [.120] Pilot, 13.59 [.535] Dia. Mounting Holes On 106.35 [4.187] Dia. B.C. |
| Output_Shaft_Type: | Spline |
| Port_Type: | Manifold Ports (.3125-18 UNC-2B Mounting Holes) |
| Flow_Rate: | 57 litre per minute |
| Maximum_Speed: | 607 revolutions per minute |
| Torque: | 183 newton metre |
| Two_Speed_Ratio: | None |
Features:
• 4 Mounting Options
• 12 Output Shaft Options
• 4 Porting Options
• Can Be Equipped With A Speed Sensor
• Available With Relief Valve
• Freeturning Displacement Available
