Putzmeister Concrete Pump Parts Hydraulic Drive Motor 151H1016

BMH indroduction:

This motor is a Gerotor Hydraulic Motor, also called Orbit Hydraulic Motor, or Low Speed High Torque Hydraulic Motor, also spool valve hydraulic motor.

Characteristics:

This motor produced by Hanjiu Technology from China, it's a alternative gerotor hydraulic motor to OMH series, also alternative with M+S MH series, and alternative with many other manufacturers from USA and European.

What benefit can i get?

As it's performance is 98% near the below manufacturers, however it's price is more than 50% lower than the below manufacturers, it has been widely used in the Agricultural, forestry, mining machinery, construction plant, access platforms, special vehicles, aeria plant, and many more hydraulic systems that need rolling, lifting, conveying applications.

• Hanjiu BMH-500-4MDB = OMH series, from Danmark
• Hanjiu BMH-500-4MDB = M+S MH series, from Bulgaria
• we have strong ability to match OEM part no. and provide you.
• BMH-500-4MDB replace Putzmeister OEM
• BMH-500-4MDB replace  151H1016

This motor is widely used on concrete pumps of Putzmeister, Schwing, Sebhsa, Sermac, Daf, Man, Mercedes-Benz,...If you are in construction aftermarket parts industry, this motor will help you to enlarge your market, If you sell $1,000,000 a year, you raise profit by at least 30%, f you sell $1,000,000 a year, your profit raised by at least $300,000.

• BMH-500-4MDB
• 151H1016
• 35mm shaft, 10x8x45
• 4 hole oval flange
• pilot 82.55mm
• oil ports G1/2
• drain G1/4

Specifications/ Technical Data:

This Gerotor Hydraulic Motor BMH is a small motor compare with other series like BMS(OMS,MS, MSY), BMT(OMT, MT), BMV(OMV, MV), it's displacement start from 200 ml/r to 750 ml/r, speed from 155 rpm to 439 ml/r, torque from 510 N.m to 1170 N.m, max output from 11 kw to 18.5 kw, max flow from 75 L/min to 90 L/min. Below is the detail specifications of this BMH gerotor hydraulic motors.
