Fully Automatic Flute Laminating Machine For Cartons With Famous Brand Electric
Price:
USD + Set
MOQ:
1
Delivery Time:
20 days
Brand:
ZL
Product Description
Fully Automatic Flute Laminating Machine For Cartons With Famous Brand Electric
Description:
The flute laminating machine is to glue facial paper and corrugated board together. The bottom paper must be corrugated board. The top paper should be 150-600g, the bottom paper can be two layer, three layer, four layer and five layer, flute can be A/B/C/E, not more than 12mm thick. This machine is very popular and used widely.
Features:
- The flute laminating machine uses touch screen control, PLC, servo motor control system, the electric is famous brand, circuit system is stable. It can dispaly the failure alarm automatically, very safe.
- The vacuum suction type feeding can feed the paper into the machine accurately, also the facial paper is stacking automatically.
- The bottom paper is vacuum suction feeding, accdording to the speed of the facial paper, it can catch up it automatically.
- Automatic gluing and glue cycling can avoid glue waste.The glue roller is easy to clean.
- The counting section can record the quantity of work you have done.
Main specification:
| model | 1300 | 1500 | 1600 |
| max feeding size | 1300x1100mm | 1500x1100mm | 1600x1250mm |
| min feeding size | 400x400mm | 400x400m | 400x400mm |
| speed | 100 pcs/min | 100 pcs/min | 100 pcs/min |
| precision | ±1.5 | ±1.5 | ±1.5 |
| power | 10kw | 12kw | 12kw |
| dimension | 10x2x2.4m | 10x2.15x2.4m | 10x2.25x2.4m |
| weight | 5t | 6t | 6t |
