Automatic Corrugated Board Assembly Partition Machine / ZL Clapboard Assembler Partition Machine
Automatic Corrugated Board Assembly Partition Machine /ZL Clapboard Assembler Partition Machine
The description of machine
Application and characteristics
BL500 serious automatic partition assembler machine is optimized to be a new partition assembler devices on the basis of absorbing the advantage of equipment at home and abroad in our factory. The equipment takes the place of the traditional manual operation made, automatic complete insertion of clapboard , saving labor costs, effectively improve the production efficiency at the same time. It is the ideal packing equipment of fruit and vegetable, glass ceramic, plastic and so on.
Structure features
- Suitable for the auto insertion of all kinds of carton clapboard.
- Vertical direct using vacuum adsorption feeding , landscape orientation using servo feeding , quick and accurate .
- Longitudinal and transverse to cross the two pieces of paper at the same time.
- Longitudinal feeding shaft adopts electric lifting .
- Landscape orientation feeding worktable lifting adopts electric adjustment .
- Electric adjust the clapboard height in landscape orientation .
- Output in double work positions, high efficiency and energy saving.
- Touch screen input control, electric to adjust the clapboard parameters .
- Comprehensive using of pneumatic and electric control, to ensure the advancement of machine control .
- Using compressed air storage tanks for gas centralized supply, gas supply pressure stability, enough gas source.The gas devices get the gas from the primary tracheal , independent control, no influence between each other .
- Equipped with fault detection device, auto stop the machine when paper blocking .
The technological parameter
| power | 10kw | Not include air compressor |
| Host belt speed | 15-30m/min | |
| Clapboard combining form | 3*(1~n) | In double working station |
| Longitudinal clapboard feeding track No. | 6 | |
| Horizontal clapboard feeding track No. | 1~12 | |
| Clapboard size | Length L=120~500mm | Clapboard thickness 1.5~7mm |
| Height H=75~200mm | ||
| Width W=120~500mm(double station) | Width W=120~900(single station) | |
| Lattice space C=40~150mm | ||
| Lattice space D=30~150mm | ||
| Working speed | 30-60groups/min | Working speed is connected with clapboard size and clapboard combining form |
| Machine weight | 3000kg | |
| Overall dimension | 5500x2200x2000mm | |
|
Note: when width of clapboard is greater than 450mm, the machine just can work in single station. Air compressor or air compressor station requirement: 6kgf/cm². For the special type of clapboard, we can customize the machine as client’s wish. |
||
 |
 |
