BFY Series Thin Blade Slitter Scorer For Slitting Cardboard 120pcs/ Min Speed
BFY Hot Sale Series Thin Blade Slitter Scorer For Slitting Cardboard
Functions and features:
- Feeding department:The function buttons on the controlling panel are simple and concentrated, which are convenient to operate.
- Printing department:The printing roller and the trace pressing roller made by steel materials of high quality, which is grind well on surface and chrome-plated.
- Slotting department:Big size carton box or kicking paperboard slotting can save loading knife time with a better scope of adjusting.
- Die cutting department:The phase of die cutting roller use the adjustment of PLC and 360°electric number. Adjustment can be done when the machine works as well as stops.(PLC and the touch screen adjustment can be an option)
Technical parameters:
| Parameter | Unit | Model |
| BFY-1800 | ||
| Feeding width | mm | 1800 |
| Max. speed | m/min | 150 |
| blade and scorer | 4 blade 6 scorer | |
| Min. Separate slitting width | mm | 200 |
| Min. creasing width | mm | 200 |
| External diameter of thin & round blade | mm | 260 |
| Thickness of thin & round blade | mm | 1 |
| Power | kw | 4 |
| Weight of machine | kg | 2500 |
| Exterior dimension | mm | 3050x1791x1130 |
Service:
1. Q: How does your factory do regarding quality control?
A: Quality is priority. We always regard great importance to quality controlling from the very small thing (even a small screw we will choose the best quality) from the beginning.
2. Q: What is your after-sales service?
A: Our after-sales service is first class. We have a powerful team to help you solve problems.The Warranty is one year and if the machine is damaged by natural not by human, we can send the new parts to you for free.
3. Q: What is the terms of payment you accept?
A: 30% T/T in advance, 70% T/T balance before delivery. We also accept L/C and Western Union.
4. One year warranty
