High Definition LED Display P1.25 Small Pixel Indoor Video Wall Lightweight Stage
Price:
Negotiable
MOQ:
10sqm
Delivery Time:
20days
Brand:
TBC
Product Description
HD Indoor LED Display P1.25 Small Pixel Clear Video Wall Lightweight Stage Use
Parameters:
| Parameter | Unit | Value | ||
| Brightness | nits | 600 | ||
| Color temperature | deg.k | 3200 ~ 9300 | ||
| Viewing angle - Horizontal | deg. | 160(+80/-80) | ||
| Viewing angle - Vertical | deg. | 160(+80/-80) | ||
| Cabinet weight | kg | 7 | ||
| Cabinet width | mm | 640 | ||
| Cabinet height | mm | 360 | ||
| Cabinet depth | mm | 80 | ||
| Cabinet area | sq. m. | 0.23 | ||
| Cabinet material | Aluminum | |||
| Aspect ratio | 16:9 | |||
| Ingress protection (Front/Rear) | IP | IP40/IP20 | ||
| Operating temperature range | deg. C | 0 to 40 | ||
| Operating humidity range | HR | 10％ to 90％ | ||
| Pixel type and configuration | R/G/B | SMD 3in1 | ||
| Pixel pitch | mm | 1.25 | ||
| Pixel matrix per cabinet | 512x288 | |||
| Pixels per cabinet | 147456 | |||
| Lines per meter | 800 | |||
| Pixels per sq. meter | 640000 | |||
| LEDs per sq. meter | 640000 | |||
| Recommended minimum viewing distance | m | 1 | ||
| Colours | 281trillion | |||
| Gray scale | Levels | 65536 levels per colour | ||
| Brightness control | Levels | 100 | ||
| Digital processing | bit | 16 | ||
| Frame rate | Hertz | 60 | ||
| Display refresh rate | Hertz | 3840 | ||
| Input voltage | VAC | 110/240 | ||
| Input power frequency | Hertz | 50/60 | ||
| Input power (max/avg) | Watts per sq.m | 820/280 | ||
| MTBF | Hours | ≥10000 | ||
| Lifetime (50%Brightness) | Hours | ≥100000 | ||
| Module brightness uniformity | ＜5％ | |||
| Blind spot rate | ＜0.0001 | |||
| Earth leakage current | mA | ＜2 | ||
| Red wavelength | nm | 623 | ||
| Green wavelength | nm | 525 | ||
| Blue wavelength | nm | 470 | ||
| Panel input format (with video processor) | VGA,DVI,SDI,YPbPr(HDTV),Composite,S-Video,TV | |||
| Data interconnection | CAT6 cable/Fiber | |||
| Operating system | Windows(XP/Vista/7/8/10) | |||
| Control distance | Up to 180 meters by CAT6 cable, single fiber up to 15 kilometers. | |||
Application:
TBC HD led screens have widespread applications. In shopping malls, they can be used to showcase the latest products and promotions. Offices can utilize them for video conferences and data visualization. Meeting rooms can benefit from clear and engaging presentations. Hotels can enhance the guest experience in lobbies and event spaces. Restaurants and cafes can create a charming ambience. Concert halls can provide immersive visuals for performances. Public places such as stadiums and airports can display important information. Buildings can use them for architectural lighting and branding. Churches can enhance worship services. Cinemas can upgrade the screening experience. Advertising media can capture attention with dynamic content. And for stage rentals, they add a professional touch to events and shows.
