500x500mm P2.6mm Giant Series Outdoor Stage Rental LED Screen Display Lightweight and 7.5kg
500x500mm P2.6 Giant Series Outdoor Stage Rental LED Screen Display
1. High Contrast: Exceptional contrast ratio of 5000:1 for vibrant visuals.
2. Superior Refresh Rate: Impressive refresh rate of 3840Hz for smooth playback.
3. Wide Viewing Angle: 160° viewing angle ensures optimal visibility from various positions.
4. Durable Design: Constructed with die-cast aluminum cabinets weighing 7.5kg and measuring 80mm thick, facilitating easy transport and setup.
5. Versatile Shapes: Capable of creating curved displays with increments of 2.5° between -10° and 10°, adaptable to both rectangular and irregular formats.
6. Removable Power Box: Simplifies maintenance and setup.
7. Corner Protection: Innovative LED corner protection design safeguards each cabinet corner effectively.
8. Dual Maintenance: Front and rear serviceability with magnetic LED panels for quick removal within 5 seconds, reducing downtime.
9. Reliable Quality: Certified with CE, RoHS, and FCC for assured quality and safety.
10. Customizable Sizes: Flexible assembly options with 500x500mm and 500x1000mm cabinets to meet specific size requirements.
| Giant 2.6mm | |
| Pixel Pitch | 2.6mm |
| Pixel Configuration | SMD1415 |
| Pixel Density | 147,456 pixels/m2 |
| Module Dimensions(W x H) (mm) | 250 x 250 |
| Panel Dimensions (mm) |
500 x 500 x 80 |
| Modules Per Cabinet (W x H) | 2 x 2 |
| Cabinet Resolution | 192 x 192 |
| Panel Material | Die Cast Aluminum |
| Weight per Cabinet | 7.5kg |
| Digital Processing | 16bit |
| Colours | 281 trillion |
| Contrast Ratio | 5,000 : 1 |
| Average Power Consumption | 200 W /Sqm |
| Max Power Consumption | 650 W /Sqm |
| Brightness | >5,000 nits |
| Refresh Rate | >3,840Hz |
| Vertical Viewing Angle | 160° |
| Horizontal Viewing Angle | 140° |
| Expected Lifetime | 100,000 Hrs |
| Servicing | Front |
| IP Rating (Front/Rear) | IP 68 |
| Operating Temp/Humidity | -20ºC - 50ºC / 10% - 90% |
| Storage Temp/Humidity | -20ºC - 50ºC / 10% - 90% |
| Scan Method | 1/21 Scan |
