Ultra-Portable 500x500mm Rental LED Screen with 3840Hz Refresh Rate and Quick-Release Modular Design for Stage Displays
Price:
Negotiable
MOQ:
10sqm
Delivery Time:
15 working days
Brand:
TBC LED
Product Description
TourLite 500x500 Rental LED Screen
Ultra-portable LED display solution designed specifically for concert tours and mobile events requiring frequent setup, teardown, and transport.
Engineered for touring rental teams and mobile event planners, the TourLite 500x500mm Rental LED Screen delivers exceptional portability without compromising performance. Featuring a 3840Hz refresh rate, ultra-lightweight construction, and quick-release modular design, it's the ideal solution for concerts, roadshows, and events demanding rapid deployment.
Key Construction Features
Built with high-strength aluminum alloy frame, each panel weighs only 6.8kg (1.2kg lighter than standard models) with a slim 72mm profile. This lightweight design enables single-person handling while maximizing truck space efficiency—accommodating 20% more panels per load compared to traditional rental screens.
Display Performance
Premium SMD LED modules deliver 6000nits brightness and 95% DCI-P3 color gamut. The 3840Hz refresh rate ensures flicker-free performance for fast-moving concert footage and dynamic stage lighting effects.
Technical Specifications
| Specification | Giant 2.9mm | Giant 3.91mm | Giant 4.81mm |
|---|---|---|---|
| Pixel Pitch | 2.976mm | 3.91mm | 4.81mm |
| Pixel Configuration | SMD1415 | SMD1921 | SMD1921 |
| Pixel Density | 86,016 pixels/m² | 65,536 pixels/m² | 43,264 pixels/m² |
| Module Dimensions (W x H) | 250 x 500mm | 250 x 250mm | 250 x 250mm |
| Panel Dimensions | 500 x 500 x 80mm 500 x 1000 x 80mm |
500 x 500 x 80mm 500 x 1000 x 80mm |
500 x 500 x 80mm 500 x 1000 x 80mm |
| Modules Per Cabinet (W x H) | 1 x 2 | 1 x 2 | 1 x 2 |
| Module Resolution | 168 x 84 | 128 x 64 | 104 x 52 |
| Cabinet Resolution | 168 x 168 | 128 x 128 | 104 x 104 |
| Panel Material | Die Cast Aluminum | Die Cast Aluminum | Die Cast Aluminum |
| Weight per Cabinet | 7.5kg | 7.5kg | 7.5kg |
| Digital Processing | 16bit | 16bit | 16bit |
| Colors | 281 trillion | 281 trillion | 281 trillion |
| Contrast Ratio | 5,000:1 | 5,000:1 | 5,000:1 |
| Average Power Consumption | 200 W/m² | 200 W/panel | 200 W/panel |
| Max Power Consumption | 650 W/m² | 650 W/panel | 650 W/panel |
| Brightness | >5,000 nits | >5,000 nits | >5,000 nits |
| Refresh Rate | >3,840Hz | >3,840Hz | >3,840Hz |
| Vertical Viewing Angle | 160° | 160° | 160° |
| Horizontal Viewing Angle | 140° | 140° | 140° |
| Expected Lifetime | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs |
| Servicing | Front | Front | Front |
| IP Rating (Front/Rear) | IP68 | IP68 | IP68 |
| Operating Temp/Humidity | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% |
| Storage Temp/Humidity | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% |
| Scan Method | 1/21 Scan | 1/16 Scan | 1/13 Scan |
Innovative Features
- Quick-Release Locking System: Tool-free snap locks enable 2x faster assembly—build a 4m-wide stage backdrop in just 10 minutes, perfect for tight tour schedules
- Tour-Grade Durability: Reinforced corner bumpers and scratch-resistant coating protect against road wear, with shock-absorbent packaging for transit protection
- Detachable Battery Power Option: Optional rechargeable batteries provide 4-hour runtime for cable-free setups in outdoor venues or locations with limited power access
- Minimal Curvature for Stage Use: Pre-set -5°/0°/+5° curvature brackets simplify curved stage backdrops without manual calibration—ideal for concert arches and wrap-around designs
- Integrated Rigging Points: Built-in, load-tested rigging holes eliminate extra mounting hardware, supporting up to 50 panels in a single array for secure ceiling hangs
- Tour Management Software: WiFi synchronization enables remote monitoring of power status, pixel health, and content playback—minimizing on-site troubleshooting during shows
Applications
Ideal for concert tours, music festivals, mobile roadshows, and pop-up events—any scenario where speed, portability, and durability are essential requirements.
Benefits for Rental Professionals
The ultra-lightweight design reduces labor costs with fewer staff needed for setup, while compact dimensions lower shipping and storage expenses. Battery power expands venue options by eliminating reliance on nearby outlets. Tour-grade durability minimizes repair costs from transit damage, and the 3840Hz refresh rate ensures broadcast-quality visuals for live streams, satisfying both artists and event planners.
