Colombia Outdoor Advertising Led Display SMD High Brightness IP68 Protection
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
TBC
Product Description
Colombia Outdoor Advertising Led Display SMD High Brightness IP68 Protection
Introduction:
24sqm outdoor S series advertising display on the main street
Outdoor full color fixed installation series
Aluminum based module
IP68 outdoor protection grade
Front and rear maintenance
Features and Advantages:
1. Using high efficiency IC driver and improved PCB design, low power consumption;
2. Persistent uniformity, contrast and flatness, increasing the profit and competitiveness of the operator;
3. Anti-UV module mask, Anti-Oxidation module frame with protection from deformation;
4. Military-grade connectors of the power and signal to ensure stable connection and high duribility;
5. Ip68 weather protection grade, durable cabinet design make the LED screen reliable in all weather outdoor environments.
Parameters
| Brightness | nits | 6000-7000nits | ||
| Color temperature | deg.k | 3200 ~ 9300 | ||
| Viewing angle - Horizontal | deg. | 140(+70/-70) | ||
| Viewing angle - Vertical | deg. | 140(+70/-70) | ||
| Cabinet weight | kg | 46 | ||
| Cabinet width | mm | 960 | ||
| Cabinet height | mm | 960 | ||
| Cabinet depth | mm | 140 | ||
| Cabinet area | sq. m. | 0.92 | ||
| Cabinet material | Aluminum | |||
| Aspect ratio | 1:1 | |||
| Ingress protection (Front/Rear) | IP | IP68 | ||
| Operating temperature range | deg. C | - 20 to 50 | ||
| Operating humidity range | HR | 10％ to 90％ | ||
| Pixel type and configuration | R/G/B | SMD 3in1 | ||
| Pixel pitch | mm | 10. | ||
| Pixel matrix per cabinet | 96x96 | |||
| Pixels per cabinet | 9216 | |||
| Lines per meter | 100 | |||
| Pixels per sq. meter | 10000 | |||
| LEDs per sq. meter | 10000 | |||
| Recommended minimum viewing distance | m | 10 | ||
| Colours | 281trillion | |||
| Gray scale | Levels | 65536 levels per colour | ||
| Brightness control | Levels | 100 | ||
| Digital processing | bit | 16 | ||
| Frame rate | Hertz | 60 | ||
| Display refresh rate | Hertz | 1920 | ||
| Input voltage | VAC | 110/240 | ||
| Input power frequency | Hertz | 50/60 | ||
| Input power (max/avg) | Watts per sq.m | 500/200 | ||
| MTBF | Hours | ≥10000 | ||
| Lifetime (50%Brightness) | Hours | ≥100000 | ||
| Module brightness uniformity | ＜5％ | |||
| Blind spot rate | ＜0.0001 | |||
| Earth leakage current | mA | ＜2 | ||
| Red wavelength | nm | 623 | ||
| Green wavelength | nm | 525 | ||
| Blue wavelength | nm | 470 | ||
| Panel input format (with video processor) | VGA,DVI,SDI,YPbPr(HDTV),Composite,S-Video,TV | |||
| Data interconnection | CAT6 cable/Fiber | |||
| Operating system | Windows(XP/Vista/7/8/10) | |||
| Control distance | Up to 180 meters by CAT6 cable, single fiber up to 15 kilometers. | |||
