UL94 HB Silicone Rubber Testing Equipment Vertical Flame Test
It is suitable for testing the noncombustibility of plastics or films under the direct combustion of specified fire source to judge the fireproof grade of plastics.
Stadards:
UL94
The flame retardant grades of plastics increase gradually from HB, V-2, V-1 to V-0:
1. UL94V0, V1, and V2 are different flame retardant grades, their grades are different, the flame resistance test methods are also different, and the standards for test judgment are also different.
2. The test method of V0 is to tilt the test object at 45 degrees, ignite it with an alcohol lamp, remove the fire source, and extinguish it within 10 seconds.
3. The test method of V1 and V2 is the same as that of V0. The difference is that after the open source is moved, the extinguishing time is longer than that of V0.
4. That is, V0 has the best flame retardancy, V1 is the second, V3 is the third, and V4 is the same as the non-flame retardant.
Main feature:
| Burner Mounting Fixture: |
| 20 degree from vertical axis (used in 5VA,5VB) |
| Ring stands |
| for horizontal and vertical postioning of specimen or wire gauge |
| Timing devices- accurate to 0.1sec |
| Wire gauze: |
| approximatel 20 opening per 25mm |
| made with 0.43±0.03mm diameter iron or steel wire and cut to approx 125mm squares (used in HB) |
| conditioning room or chamber : 23± 2 deg C temp |
| Humdity 50±10 % |
| HB support Fixture-(used in HB) |
| Micrometer- capable of being read to 0.01mm |
| cotton- a supply if absorbent 100% cotton |
| dessicator- containing anhydrous calcium chloride |
| maintaining at relative humidity exceeding 20% at 23±2deg C |
| conditioning oven- min of 5 air changes per hour, maintained at 70±2deg C |
| specimen mandrel form- 12.7±0.5mm diameter rod with min 250mm length (used in VTM-0, VTM-1, VTM-2) |
| Tape-pressure sensitive adhesive (used in VTM-0, VTM-1, VTM-2) |
| Support gauze (used in HBF, HF-1, HF-2) |
| wire cloth plain weave, low caron, plain steel or stainless steel |
| approx 215mm longX75mm wide having 13mm length bent to form a right angle at one end |
| cloth mesh and wire dia to be determined as per ASTM E 437 |
| Foam support fixture(used in HBF, HF-1, HF-2) |
| Model | DX8379-UL94 |
| Dimensions | About 7, 000 (w) X4, 000 (D) X4, 000 (H)m |
| Power supply | AC 380V, 50/60Hz |
| Brochure | Can provide |
| Air Velocity | 19±8 Km/h |
|---|---|
| Tools | Propane gas/liquefied natural gas, Compressed air, Vacuum cleaners, Computer |
