ASTM D2303 Insulator Testing Equipment High Voltage Tracking Index Tester DX8427 100-8000V
Price:
Negotiable
MOQ:
1 Set
Delivery Time:
5-8 Work Days
Brand:
DAXIAN
Product Description
ASTM D2303 Insulator Testing Equipment High Voltage Tracking Index Tester
The DX8427 High Voltage Tracking Index Tester is designed to fully comply with IEC60587-2007 and ASTM D2303 standards, used to evaluate the resistance of insulating materials and insulators to tracking and erosion under high voltage and contaminant conditions.
Key Features
- Full Standards Compliance: IEC60587-2007 & ASTM D2303 high voltage tracking and erosion test.
- Wide Voltage Range: AC 0-6000V and DC 0-8400V stepless adjustable test voltage.
- Precise Drip Control: Liquid flow range 0.0016-1.5ml/min with 0.5% dropping precision.
- Adjustable Drop Height: 30mm-40mm adjustable drop height with 1.00N±0.05N electrode pressure.
- Safety Protection: Automatically stops dropping liquid and cuts off voltage when loop current exceeds 60mA.
- Stainless Steel Electrodes: 0.5mm thick stainless steel electrodes with 50.0mm±0.1 gap.
Technical Specifications
| Parameter | Specification |
|---|---|
| Standard | IEC60587-2007, ASTM D2303 |
| Test Voltage | AC 0-6000V / DC 0-8400V adjustable |
| Test Voltage Power | 6000W |
| Drop Height | 30mm-40mm adjustable |
| Electrode Pressure | 1.00N±0.05N |
| Electrode Gap | 50.0mm±0.1 |
| Liquid Flow Range | 0.0016-1.5ml/min |
| Chamber Volume | ≥ 0.5 m³ |
| Dimensions | 1500L*1050W*2000H (mm) |
| Warranty | 12 Months |
Applications
Ideal for insulator manufacturers, cable and electrical material producers, and third-party laboratories performing high voltage tracking and erosion resistance tests on insulating materials, silicone rubber and polymeric insulators.
