DIN EN 60587-2008 High Voltage Tracking Testing Equipment For Electrical Insulating Materials
IEC60587 Electrical Insulating Materials Resistance To Tracking And Erosion Testing Equipment
Technical Description:
High Voltage tracking tester suit for electronic products, household appliances and other materials resistance to tracking and erosion test, simulate the frequency (48HZ-62HZ) or a corresponding DC Voltage, liquid contaminants and ramps samples by electrical resistance to tracking and erosion measurements assessed under severe environmental conditions of electrical insulating materials resistance to tracking and erosion levels.
Standard:
- ASTM D2303
- DIN EN 60587-2008
- IEC 60587-2007.
Parameters:
|
Box |
≥ 0.5 cubic meters |
|
Drop size |
44 to 50 drops / cm3 |
|
Power supply |
AC 220V, 50Hz |
|
Electrical load |
100 ~ 6000V adjustable |
|
Drip height |
30mm ~ 40mm adjustable |
|
Electrode Pressure |
1.00N±0.05N |
| Flow range | 0.00185 to 2 ml / min |
| Working speed | 0.1 to 15 rev / min |
Our products:
1. Fire Testing Equipment
2. Building Material Fire Tester
3. Wire and Cable Fire Tester
4. Environmental Test Chamber
5. Textile Testing Equipment
6. Plastic Testing Equipment
7. Tensile Testing Machine
FAQ:
Q:Are you factory or trading company?
A:We are factory in Dongguan City, Guangdong Province,China.Near Shenzhen or Guangzhou.
Q:What kind of certificate you have?
A:ISO9001 Certification, CE Certification.
Q:What is the lead time of the product?
A: Generally 7-15 days after getting the deposit.
Q:How about the payment term?
A: T/T, by cash, western union, or L/C.
Q:How about the warranty term?
A:1 year warranty,The engineer can teach the machine on the spot.
