HOWO 6*4 10 Crawler Dump Truck 41000kg Tires Tipper Truck For African Market
Price:
Negotiation
MOQ:
1 pc
Delivery Time:
15 days
Brand:
Bilon
Product Description
HOWO 6*4 10 Tires Tipper Truck For Africa
Single sleeper, all-steel forward control, 70° hydraulically tillable to the front, 2-arm windshield wiper system with three speeds,laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, exterior sun visor, adjustable roof flap, stereo ratio/cassette recorder, safety belts, adjustable steering wheel, air horn, airconditioner, with 4-point support fully floating suspension and shock absorbers.
| Engine | Model | 615.62 | 615.87 | 615.69 | W15.47 |
| Power | 266 hp | 290 hp | 336 hp | 371 hp | |
| KW/rpm | 196/2200 | 213/2200 | 247/2200 | 273/2200 | |
| Displacement | 9.726 L | ||||
| Transmission | HW13710/HW19710 ( 10 forward , 2 reverse , with direct connect PTO ) | ||||
| Front Axle | HR9 (Drum Braking) Max.loading:9000 kg | ||||
| Rear Axle | HC16 (Drum Braking) Max.loading:16000 * 2 kg Ratio : 4.8/5.73 | ||||
| Steering | ZF8118,hydraulic steering with power assistance | ||||
| Braking System | Service brake: dual circuit compressed air brake Parking brake:spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust brake |
||||
| Electrical System | Operating voltage:24 V, negative grounded Starter:24 V,5.4Kw Alternator:3-phtase,28 V,758 W Batteries:2×12 V,135Ah Cigar-lighter, horn, headlamps, fog lights, indicators and reverse light |
||||
| Wheel Tyre | Tyres: 12.00R20 raidial tyreOption: 315/80R22.5,295/80R22.5,12.00-20 | ||||
| Body Dimension(mm) | 4800x2300x1200 | 5200x2300x1400 | 5600x2300x1400 | 5800x2300x1400 | |
| Body Shape | rectangle shape/ U shape / volve shape / mining body | ||||
| Hydraulic Cylinder | ventral tipping / front tipping | ||||
| Thickness of Body | Floor 8 / 10 mm | Side 8 / 6 / 4 mm | |||
