92KW 2 Axles 933L 3 Ton Large Wheel Loader Machine For Construction
Price:
Negotiable
MOQ:
1-10pcs
Delivery Time:
30 days
Brand:
Bilon
Product Description
933L Chinese 3 Ton Large Wheel Loader For Construction Machinery for Sale
1,Type: Water-cooled, four stroke, direct injection
2,Torgue converter:single-stage three-element single-turbine torque converter
3,Type:Load sensing full hydraulic articulated steering
| Basic configuration | |
| Engine | Weichai WP6G125E23 |
| Transmission system | Fixed shaft power shift, SDLG reinforced drive axle |
| Hydraulic system | Mechanical |
| Lift arm | Standard |
| Control valve | 2-joint valve |
| Brake system | Dual brake pedal |
| Cab | Standard |
| Heating & Cooling | Heater |
| Other configuration | Engine tachometer |
| Detailed configuration | |
| Overall dimension | |
| L*W*H | 6970*2520*3240mm |
| Wheel base | 2700mm |
| Min. ground clearance | 375mm |
| Max. dumping height | 2950mm |
| Lifting height | 3790mm |
| Dumping distance | 1050mm |
| Dumping angle | 45° |
| wheel tread | 1865mm |
| steering angle | 36° |
| horizontal crossing radius | 5945mm |
| Min. turning radius | 5120mm |
| Overall parameters | |
| Backet capacity | 1.8m3(1.5-3.0) |
| Rated load | 3000kg |
