Industrial Sanitary 20 Stainless Steel Filter Housing For Pure Water Treatment System
Industrial Sanitary 20 Stainless Steel Water Filter Cartridge Housing For Pure Water Treatment System
Features and Benefits
- Mirror Surface Finish Complete Stainless Steel Constructiona).:Reduces bacterial/particle adhesion and no dead space;Excellent corrosion resistance;
- Easy To Install Design With Sanitary Connections, Easy to Clean.:Available in tri-clamp, flanged and thread connections;Rrequires minimum floor space and quickly dismantles for easy cleaning;
- Housings Accommodate From One (1) to Many 10", 20", 30" or 40" Cartridgesa). :Suitable for small to large batch sizes and flow rates;High pressure & high temperature designs are available;
- Clean-in-Place (CIP) /Steam-in-Place (SIP) Design
Typical Applications
- Water Treatment, RO system;
- Pharmaceuticals, API, Biologics;
- Food and Beverage, Wine, Beer, Dairy, Mineral Water;
- Paints, Inks Plating Solutions;
- Process Chemicals and Electronics Industry;
Industry Application
1. Reverse Osmosis Pretreatment
2. Chemical & Petrochemical
3. Dairy
4. Drinking Water
5. Food and Beverage
6. Liquid Desalination
7. Electronics
8. Fuel Material Extraction
9. Pharmaceuticals & Biotechnology
10. Pulp & Paper
11. Wastewater Reuse/Recycled Water
12. Power Generation
13. Industrial Water Treatment
Features and Specifications
Band V-Clamp Top Closure for Quick and Easy Cartridge
Replacement, Side-In and Side-Out Connections, Built-In
Drain and Vent Ports, Side Ports for Inlet/Outlet Pressure
Gauges, Available with Threaded or Flanged Fittings for
Easy Installation, Housings are Compatible with Standard 2.5" OD × 30" Length Melt-Blown or Wound, Polypropylene Filter Cartridges
Materials of Construction:
o Available in 316L Stainless Steel with Electropolish
Finish or in 304 Stainless Steel with Poly Coat Finish.
Operating Limits:
o Maximum Operating Pressure: 150 psi (10 bar)
o Maximum Operating Temperature: 250°F (120°C)
