EN 1.4526 AISI 436 Stainless Steel Cold Rolled Sheets And Coils
AISI 436 , EN 1.4526 cold rolled ferritic stainless steel sheet and coil
Stainless 436 is an improvement of type 434 with a small stabilizing Niobium addition.
Type 436 is a 1% molybdenum-alloyed ferritic stainless steel with medium chromium content.
It is suitable for use in many corrosive environments, like for instance in the cold end of automotive
exhaust systems. Because of its titanium alloying, 436 stainless can be welded in all dimensions
without becoming susceptible to intergranular corrosion.
Designation
| EN | DIN | AISI | UNS | JIS |
| 1.4526 | X6CrMoNb17-1 | 436 | S43600 | 436 |
Chemical composition ( % weight )
| Grade | C | Si | Mn | P | S | Cr | Ni | Mo | Nb |
| 436 | 0.12 max | 1.00 max | 1.00 max | 0.040 max | 0.030 max | 16.00~18.00 | - | 0.75~1.25 | 5XC min, 0.80 max |
Typical mechanical properities
| Grade | Tensile strength | Yield strength | Elongation % in 2'' | Hardness |
| 436 | 517 MPA | 310 MPA | 28 | HB75 |
Product forms
Hot-rolled wide strip, cold-rolled wide strip, slit strip, cut sheets, precision strip
