EN 1.2083 DIN X40Cr14 Stainless Tool Steel Sheets AISI 420 Plates
EN 1.2083 DIN X40Cr14 Stainless Tool Steel Sheets AISI 420 Plates
TYPE DIN 1.2083 is a chromium alloyed stainless plastic mould tool steel.
Characterised by a combination of toughness, corrosion resistance and the ability to reach
uniform hardness throughout large cross sections. 1.2083 has the added benefits of steel that possesses
good wear resistance and excellent polishability.
The combination of these properties provides a steel with outstanding performance which makes 1.2083
tool steel particularly suitable for moulds for chemically aggressive plastics. Industries: Plastics, Medical,
Pharmaceutical, Chemical etc.
Moulds for chemically aggressive products, moulds for optical products, moulds for medical products,
mould and pressure tools, tooling and inserts for corrosive plastics and polymers, larger moulds due to
outstanding through hardening abilities.
Standards
| EN | DIN | JIS | AISI |
| 1.2083 | X40Cr14 | SUS420J2 | 420 |
Chemical composition %
- Carbon 0.36 - 0.42%
- Chromium 12.50 - 14.50%
- Manganese 1.00% max
- Phosphorous 0.03% max
- Silicon 1.00% max
- Sulphur 0.03% max
Product forms
DIN 1.2083 stainless tool steel sheet/plate
| Thickness | Width |
| 0.5~60.0 | max. 1250mm |
