X39CrMo17-1 (1.4122)
Stainless alloy X39CrMo17-1 is a chromium-molybdenum alloyed steel according to DIN EN 10088-2
that can be quenched and tempered.
This material DIN 1.4122 grade has also proved very well for the use of heatresistant disc springs.
Stainless martensitic steel with very good wear, corrosion reistance and industrial polishability.
Martensite 17% Cr, Material W.-Nr. 1.4122 ( DIN X39CrMo17-1 ) is used for pump shafts,
fitting and compressor parts, as well as steam and water control valves and boat shafts for use in fresh water.
Chemical composition % weight
| C | Si | Mn | Cr | Mo | Ni |
| 0.33~0.45 | 1.00 max | 1.50 max | 15.5~17.5 | 0.8~1.3 | 1.0 max |
Products are delivered in soft annealed condition, HB 280 max.
