Cold Rolled Stainless Steel Strip In Coil DIN1.4122 Grade X39CrMo17-1

Material No. W.-nr. 1.4122 ( DIN X39CrMo17-1 ) equals to DIN X38CrMo17, X38CrMo16, X35CrMo17

Stainless martensitic steel with very good wear, corrosion reistance and industrial polishability.

Material W.-Nr. 1.4122 ( DIN X39CrMo17-1 ) is used for pump shafts, fitting and compressor parts,

as well as steam and water control valves and boat shafts for use in fresh water.

Products are delivered in soft annealed condition, HB 280 max.
C 0.33/0.45, Si 1.00 max, Mn 1.50 max, Cr 15.50/17.50, Mo 0.80/1.30, Ni 1.0 max

Typical chemical composition %

Martensitic chromium steel with a carbon content permitting to obtain high tensile strength levels by heat treatment.

Increased chromium content molybdenum addition account for good resistance to the action of seawater,

organic acids and nitric acid, and also for excellent re sistance to crevice corrosion.

The material X39CrMo17-1 presents satisfactory high temperature strength, excellent wear resistance

and good antifriction properties.

Surface finish for optimum corrosion resistance: fine ground or polished.

Appliciation
Components for mechanical, marine and plant engi nee ring, pump and compressor parts, sucker rods,

cutting surgical instruments.

EN 1.4122 ( DIN X39CrMo17-1, X35CrMo17 ) martensitic stainless steel, most corrosion resistant

martensitic grade, good resistance in moderately corrosive, low chloride containing environments.

Very good mechanical properties and wear resistance. Medium-high hardness.

Applied for e.g. surgical instruments, food processing equipment, mechanical parts, machine and pump construction.
